Description Overview Working width: 3600 mm Year: 2006 Quantity: 10 Warp and Weft Systems Whip roll with electronic tension for the warp Feeding with double beam device Electronic let off Selector for 4 colors 4 weft feeder Iro Luna-X2 with control box per loom Dobby and Heald Assembly Staubli 2670B electronic dobby 16 heald levers 16 heald frames per loom 6000 heald wires per loom, standard extra so Optifil Inox (blue reed) 6000 drop wires per loom Grob LA Egu 1810EX, dim. 165 x 11 x 0.40 mm Beams and Cloth Rolls 32 half beams with flange 800 mm in aluminum, total for 10 looms 20 cloth rolls total for all 10 looms Additional Features 6 contact bars Temples for cotton Electronic loom speed control Control panel with PLC touch screen Electrical Specifications Voltage: 380 V, 3-phase, 50 Hz
