Description Overview Rotary press with cast-iron cylinder and pressing bed, for processing and pressing wool and wool blend fabrics Year: 2002 Width: 1900 mm Cylinder width: 1800 mm to 2400 mm Especially suitable for men’s wear, lady’s wear/silk, coats and overcoats Specifications Maximum working pressure: 20,000 kg Unrivalled working pressure: 20,000 kg at 40 m/min Maximum working speed: 40 m/min Installed power: 33.5 kW Steam consumption: 80-90 kg/h Compressed air minimum pressure: 5 bar Inlet fabric feed speed: 4 m/min Construction And Features Cast-iron calendering cylinder cast in one piece, diameter 600 mm Cast-iron contrast pressing bed with rectified bearing surface Automatic control and adjustment of cylinder and pressing bed temperature Pressure-free fabric ironing Spreading device at inlet Steam box before the calendering cylinder Folding device at outlet with large diameter drilled cylinder Modular construction system with touch-screen display Driving system with inverter-controlled three-phase motors Independent impulse controls for each device
