This machine is used to wash thick fabric, such as mink blanket, flannel, coral, etc.
Open-Width Into Fabric Frame
Incorporates international superior 4 mm thick plate, painted blue orange stripes embalmed.
New type of tensioning device and many cloth guide rollers, smooth cloth roller.
With a set of infrared on the device, can effectively expand the drape of fabric.
Open Washing Machine (4 Pcs)
Around the national standard of high quality stainless steel wall plate thickness 3 mm, SUS304, with 10 x 60 mm strip stiffener.
On the cloth guide roller 5 under 5 type combinations.
The cloth guide roller beam is made of stainless steel production.
Elastic frame structure is balanced, in favor of the sensitivity of tension control.
Fabric guide roller incorporates Φ125 mm high strength strong cloth guide roller.
The water drain valve for manual drain valve.
Beating Oscillation Wash Box
Frame made by welded stainless steel plate, with 4 rollers above and 4 below, diameters of which are Φ125 mm, oscillating hexagonal roll diameter 360.
The operating side of the tank is equipped with thermometer to facilitate to regulate the temperature properly.
Using hexagonal beating roll, oscillating fabric, motor 1.1 kW, frequency converter speed adjustment.
Figuration dimension (L x W x H): 1500 x 2850 x 950 mm.
2 Rollers Padder - Φ250 (4 Pcs)
Rolling to the pressure on the structure, the steel roller, rubber roller, convenient maintenance, single point. Squeezer and rubber diameter Φ250 mm.
Reinforced base, by the square tube cross arm is connected between the two base, which has the best stability. Cylinder of the size of Φ160 x 60 mm.
The roller initiative, driven by frequency converter speed reducer drive, stainless steel cladding after finishing polishing.
In rolling point with the expansion of bending roll.
Both ends with the lock cylinder, pressure gauge, reversing valve, etc.
It incorporates upper pressure type structure, stainless steel frame, motor is directly connected, and the power is 3 kW-4P. Transmission gear reducers feature cycloidal reducer, motor and reducer are joint by double chain axis.
Electrical Configuration and Control
Electric control cabinet cold-rolled steel sheet production, plastic spraying tank shell, flat door to ensure good seal, equipped with the lighting in the cabinet.
At the bottom of the inlet equipped with filter, the use of ventilation fans, installation of rat guard.
Used in frequency converter; AC motor frequency control, equipped with advanced electric control system operation, brand of high-quality precision components; effective electromechanical combination, synchronous stable performance is good.
Incorporate Schneider switch, contactor, circuit breaker and other major electrical components for the well-known brands.
With internal power master switch, controlled by inverter, transformer, insurance device, leakage prevention device, etc.
Condition
Used machine.
Included
Main supporting parts list includes: mechanical sealant (4), rubber sealing plate (6), direction valve 2/3 (6), circuit breaker (4), AC contact (4), bearing (2), pneumatic connectors (10), pressure reducing valve (2), angular displacement sensor (2), pressure gauge (2).
Buyer's Own Parts
Unloading tools, shovel, cloth car crane, large tools, and air compressor, etc.
The buyer needs to configure machine outside the pipe, the total points, power lines and cables, bridges, pipes, etc. between the motor and the electric control cabinet.
Machine of the closed steam, water control valves, pumps and sewage pipe material, etc.
Specifications
Dimensions: 10410x3700x2850mm
Fabric width: 2000mm
Machine width: 2200mm
