Electronic control of the position of the hooks and force.
Maximum capacity of 70 ton.
Work cycle single mercerization, or double mercerization.
Specifications
Use up to 10 hooks of 1 kg for total 10 kg yarn for each work cycle.
Inputs for 3 wash water, three discharges separate, input to a caustic soda, pneumatically controlled.
Each machine produces about 100 kg/h of hanks yarn 1 kg/cad. for a total of 800 kg to turn.
2 automatic loaders for hanks.
Hydraulic system 11 kW with control, oil cooling system with water, hydraulic movements at variable flow control, with 4 hydraulic cylinders controlled in position encoders.
Electrical panel with two doors with electronic PLC and Workstation control data work programs residents and selectable.
Framework to a pneumatic door.
Condition
Construction year end 1999.
