Solution feeding system with precision metering pump provides stable solution feeding
50 to 100 ml/h continuously adjustable
Rewinding Device
Unwinding device: 3 inch air expansion shaft continuous unwinding, maximum diameter 30 mm, magnetic powder maximum braking torque 12 n. m
Winding device: 3 inch air expansion shaft continuous winding, maximum winding diameter 300 mm, winding tension control range 0 to 100 n, control accuracy 0.5%
Winding speed continuously adjustable within the range of 0 to 5 m/min
Deviation rectifying device: winding includes automatic deviation rectifying, deviation rectifying precision is 1 mm
Guide rolls directly contacting the fiber membrane are treated as a release
Spinning Nozzle Device
Single set of spinning nozzles device, trapezoidal array 16 pins * 4 or 32 pins + 2
128 needles in total for spinning nozzle
Collection Platform
Base metal plate used as a grounding end or a negative electrode and a continuous non-woven fabric or a melt-blown fabric as a substrate to collect nanofiber continuously
Substrate width is 660 mm and the spinning area is > 660 mm + 600 mm
Spinning receiving distance 100 – 200 mm
Environmental Control
Temperature control adjustment range: room temperature to 50 ℃, temperature deviation ± 3 ℃
Humidity control adjustment range: indoor humidity to 30 % rh, humidity deviation ± 3% rh
Exhaust System
Exhausting method is from bottom to top, silent exhaust
Exhaust rate is approximately 120 m3/h
Drying Equipment
Accelerates the rapid evaporation of the residual solvent of the nanofiber membrane
Drying temperature adjustable within the range of 0 to 60 ℃
Power Line
220 volts and 50/60 hz
Dimension of Equipment
1500 x 1050 x 2000 mm
