Description Overview Vacuum feeder - 1 set Plastic drying hopper - 1 set Single screw extruder - 1 set Screen changer - 1 set Metering pump - 1 set Die - 1 set Belt type collecting machine - 1 set Electrostatic electret device - 1 set Slit and coiler - 1 set Hot air system and screw air compressor - 1 set Plastic Automatic Charger Feeding capacity: 200 kg/h Air pump power: 1.1 kW Hopper Plastic Dryer Volume: 100 L Feeding capacity: 50 kg Heating power: 7.5 kW Blower power: 0.12 kW Single Screw Plastic Extruder Material: 38CrMoAlA, nitriding Screw diameter: 65 mm Screw L/D: 33:1 Main motor power: 22 kW Speed adjustment: incorporates 22 kW ABB inverter Barrel heating: cast-in heater with air cooling Heating power: 18 kW Gearbox: ZLYJ series rigid gear surface gearbox Extrusion capacity: 20 to 50 kg/h Screen Changer Material: 40Cr Max working pressure: 20 MPa Metering Pump Capacity: 40 cc Rotate speed: 0 to 50 rpm, incorporates ABB AC inverter Motor power: 2.2 kW Extrusion Mould Structure: T-die Material: high quality alloy steel Width: 600 mm Air holes: 12 pcs; precise temperature control Belt Type Collecting Machine Rotate motor power: 1.5 kW Rotate speed control: incorporates ABB AC inverter Suction fan power: 3 kW x 2 sets Electrostatic Electret Device Includes electrostatic generator, voltage raiser, electret frame Generates electrostatics during production and increases the filtering efficiency Slit and Half-Off Machine and Coiler Coiling roller: diameter 200 mm, width 800 mm Slit blades: 4 pcs Coiling motor: 1.5 kW, incorporates ABB AC inverter Coiling method: self friction, inflatable shaft x 2 pcs Hot Air System Motor power: 37 kW Pressure: 0.8 MPa Capacity: 6.2 m³ per minute Air dryer: 6 Nm³ per minute Air filter: x 2 pcs Air tank: 1 m³ Heating system: heating power 40 kW
