NovaStar, Pillow Filling Machine, 4-Nozzle, Fiber Opener, 250 kg/hr, 220V 60Hz (New)

NovaStar, Pillow Filling Machine, 4-Nozzle, Fiber Opener, 250 kg/hr, 220V 60Hz

Description

  1. Overview
    1. Inventory number: E-4401-4 Nozzle
    2. New pillow filling machine (4 Nozzle) for 3 denier x 51mm siliconized virgin fiber
    3. For polyester staple fiber opening and filling into upholstery cushions or pillows
    4. Capacity 250 kgs per hour x 400 hours per month = 100,000 kgs per month at 100% efficiency
  2. Hopper Feed (Ref G-3768)
    1. Feed belt width: 1000mm
    2. Voltage: 220 volts, 60 Hz
    3. No weigh pans included
    4. Total floor space with the hopper feed is approximately 36 square meters or 360 square feet, depending how you place the filling fans
    5. Motor: 4.5 kW
  3. Fiber Opener
    1. Feed belt width: 1000mm
    2. Dimensions (mm) (L x W x H): 2050 x 1400 x 940
    3. Main drum diameter: 325mm
    4. Capacity: 250 kgs/hr
    5. 9 working cylinders diameter 56mm each
    6. Power: 6.75 kW
    7. Net weight: 600 kg
    8. Voltage: 220 volts, 60 Hz
  4. Transfer Fan
    1. Dimensions (mm) (L x W x H): 610 x 520 x 800
    2. Power: 2.2 kW
    3. Net weight: 75 kg
    4. Capacity: 850 kg/hr
    5. Voltage: 220 volts, 60 Hz
  5. Mixing Machine (Silo With Four Exits)
    1. Dimensions (mm) (L x W x H): 1840 x 1400 x 1680
    2. Power: 5 kW
    3. Net weight: 500 kg
    4. Capacity: 850 kg/hr
    5. Voltage: 220 volts, 60 Hz
  6. Filling Station (Fan) – Four Filling Fans With Nozzle Clamps and Tables
    1. Dimensions (mm) (L x W x H): 850 x 540 x 960
    2. Power: 1.5 kW each = 6 kW total
    3. Net weight total: 90 kg each
    4. Capacity: 100 to 125 kg/hr each (each filling station fan), 400 to 500 kgs per hour max
    5. Voltage: 220 volts, 60 Hz
    6. Air pressure: <0.5 MPa
    7. With automatic pneumatic clamps
    8. 4 pillow staging tables – 27 inches tall
    9. 4 Nozzles, 2 inch diameter x 24 inches long
    10. 4 Nozzles, 4 inches x 18 inches long (standard)
    11. With all foot operated pedals for fiber feed and clamp control
    12. 1 Kobalt brand, Quiet Tech model, standup compressor for the clamps and air valves (1.8hp 4-pole induction motor with oil-less pumps, 4.5cfm @90psi, 26 gallon capacity)
  7. Spare Parts Suggested
    1. One spare fan
    2. One spare opening cylinder
    3. Seven top carding cylinders
    4. One motor for hopper
    5. One photocell for hopper
    6. One motor for opening card
    7. One motor for mixing chamber
    8. One motor for filling fans
