James Hunter, Fiberlocker Model 54, 4000mm Working Width, 2 Needle Boards, 40 HP

James Hunter, Fiberlocker Model 54, 4000mm Working Width, 2 Needle Boards, 40 HP

Description

  1. Overview
    1. Inventory number: E-9303
    2. James Hunter needle loom
    3. Model Fiberlocker model 54
    4. Machine serial N4977
  2. Specifications
    1. 2 needle boards
    2. 4000mm wide (157") x 11" front to back (each board)
    3. Needle density per board is 87 needles per inch
    4. 3480 needles per board or 6960 for the two boards (per meter)
    5. Board front to back measurement = 11 inches (280mm)
    6. General Electric DC motor, 40 hp
    7. 500 volts
    8. DC drive
    9. RPM 1750/2100
    10. Armature amps 65 amps
    11. Field amps 2132/1.73
    12. Field ohms 40
  3. Dimensions
    1. Floorspace dimensions = 16 feet wide x 7.5 feet front to back (4800mm x 2250mm)
