Cleaver-Brooks, CB-200-600, 1987, 600 HP, 150 PSIG, Dual Fuel Packaged Firetube Boiler

Cleaver-Brooks, CB-200-600, 1987, 600 HP, 150 PSIG, Dual Fuel Packaged Firetube Boiler

Description

  1. Overview
    1. Inventory number: E-9446
    2. Reconditioned Cleaver Brooks boiler, model CB-200-600
    3. 600 hp, 150 psig, #2 oil and natural gas
    4. Originally manufactured in 1987 in accordance with ASME code, section 1, for a design pressure of 150 psig and is national board certified
    5. Four (4) pass dryback design
    6. Shell insulated with two inches of compressed fiberglass and covered with a heavy gauge sheet steel casing
    7. Fully modulating forced draft burner integrally mounted, piped, and wired on the boiler front for easy set-up and maintenance
  2. Factory Mounted Trim, Controls, And Ancillary Equipment
    1. Emissions – standard
    2. Dual fuel burner arrangement – standard burner
    3. Primary low water cut-off – McDonald Miller - pump control – on/off
    4. Secondary low water cut-off – McDonald Miller with manual reset
    5. Boiler valve trim including vent valve (steam stop valve not included)
    6. Front and rear hinged/davited doors
    7. Pressure gauge with isolation valve
    8. Flame safety type: Fireye E-100
    9. Boiler/burner control center consisting of starters, relays, fuse blocks, limit switches, alarm bell, indicating lights, control circuit transformer, high limit control, and manual/automatic firing rate adjustment
    10. Steam pressure limit switches; operating limit, safety limit with manual reset and modulating steam pressure controller for running operation and stand by operation
    11. Direct drive atomizing air unit, separate #2 oil pump (not included)
    12. Rigid and sealtite conduit and wiring
    13. Gas train – ITT valves/ASCO hydromotors
    14. FM insurance approvals
    15. U.L listing
  3. Connections
    1. Steam outlet: 8” x 300#
    2. Blowdown: 2” NPT
    3. Surface blow-off: 1.0” NPT
    4. #2 oil, sup & ret: 0.75” NPT
    5. Feedwater: 2.5” NPT
    6. Natural gas: 4.0” NPT
    7. Exhaust/vent: 24” ID
    8. Primary electric: 460V/3 phase/60 Hz
  4. Dimensions And Weight
    1. Length overall: 284”
    2. Shell: 222”
    3. Width overall: 123”
    4. Shell: 96”
    5. Height overall: 126”
    6. Vent: 126”
    7. Weight, shipping: 47,000 lbs
  5. Condition
    1. Reconditioned
    2. Completely retubed
    3. New fireside and waterside gaskets
    4. Hydrotested
    5. Electrically tested
    6. Repaired lagging
    7. New rear door refractory, new throat and liner tiles
    8. New paint
