NovaStar, SG115, Double-Shaft Tire Crusher, 1200mm Chamber Length, 14000kg (New)

NovaStar, SG115, Double-Shaft Tire Crusher, 1200mm Chamber Length, 14000kg

Description

  1. Overview
    1. Industrial wood chipper available in three models: SG115, Ps800, and Ps600.
    2. Crushing speed of main shaft: 8 to 14 rpm for all models.
  2. Specifications
    1. Motor power: (22-37) × 2 kw for model SG115, (18.5-30) × 2 kw for model Ps800, (18.5-22) × 2 kw for model Ps600.
    2. Number of revolution blades: 22 pcs for model SG115, 20 pcs for models Ps800 and Ps600.
    3. Crushing chamber length: 1200 mm for model SG115, 800 mm for model Ps800, 600 mm for model Ps600.
    4. Screening hole diameter: Ø50 to Ø90 mm for model SG115, Ø50 to Ø70 mm for model Ps800, Ø40 to Ø60 mm for model Ps600.
    5. Feed size: ≤Ø1200 mm for model SG115, ≤Ø800 mm for model Ps800, ≤Ø600 mm for model Ps600.
    6. Output chip size: 40 to 70 mm for model SG115, 40 to 50 mm for model Ps800, 30 to 50 mm for model Ps600.
    7. Output with filter screen: ≤3500 kg/h for model SG115, ≤2500 kg/h for model Ps800, ≤1000 kg/h for model Ps600.
    8. Output without screening: ≤8000 kg/h for model SG115, ≤5000 kg/h for model Ps800, ≤3000 kg/h for model Ps600.
    9. Machine dimensions (l × w × h): 6130 × 3670 × 2850 mm for model SG115, 5200 × 2650 × 2850 mm for model Ps800, 3700 × 2100 × 3100 mm for model Ps600.
    10. Machine weight: 14000 kg for model SG115, 12000 kg for model Ps800, 9000 kg for model Ps600.
