Benninger, Ben-Direct 1250 / Ben-Sizetec ZA20, 1998/1999, 2200mm Width, 1320 Position V-Creel, Sizing Range

Benninger, Ben-Direct 1250 / Ben-Sizetec ZA20, 1998/1999, 2200mm Width, 1320 Position V-Creel, Sizing Range

Description

  1. Overview
    1. Benninger direct high-production warper
    2. Year: 1998
    3. Model: Ben-Direct 1250
    4. Suitable for warping of natural and synthetic fiber yarns
    5. For beams 2200 mm width with flange diameter up to 1250 mm
    6. 30 beams flange diameter 1250 mm
    7. Width: 2200 mm
    8. Safety system according to the European norms
  2. Warping Specifications
    1. Warping command: 18.5 kW with 1500 rpm
    2. Max. warping speed: 1200 m/min
    3. Net tension (phase-phase): 3 x 400 V + 6% - 10%
    4. 50 Hz, 3 phases
    5. Compressed air consumption min. 5 bar 0.2 m³/h
    6. Disk brakes (hydraulic pressure) on both sides of the beam
    7. Undirect pressing system
    8. The pressure is adjustable up to 2000 to 6000 N
    9. Momentary lifting of the pressing roll at machine stop (kick-back)
    10. Reed-support for installation of an extensible zig-zag reed (50 mm segments, adjustable for 657-460 yarns) for a precise yarn-threading
    11. Impulse-blowing from the compressed air network
    12. Crossed yarns separating device
    13. Production data recording for six shifts with the following characteristics: warp length, number of warp beams, number of yarns per beam, number of the shift
    14. On-board printer
    15. Filaccumulator yarn accumulator, max capacity 7 meters
    16. Ben-Vac aspiration system
  3. Ben-Sens V-Creel
    1. Model: GE
    2. 640 positions in work
    3. 680 reserve
    4. Total: 1320 positions
    5. Bobbins at 5 levels
    6. Max. diameter 305 mm with a minimum distance between bobbins 5 mm, vertical gauge 435 mm
    7. Count from 50 to 500 dtex
    8. Integrated electronic optical device for yarn tensioning, digital indicator of number of yarns in work, indication of broken yarn
    9. Automatic pre-tensioners
  4. Benninger-Zell High Productive Sizing Range
    1. Model: Ben-Sizetec ZA20 2KAV/TD CT 4/4/6 BB 2200/4000
    2. Year: 1999
  5. Benninger Beams Creel
    1. Model ZA20 for 20 fractional beams each width 2200 mm (flange to flange)
    2. Max. flange diameter 1250 mm
    3. With air pneumatic braking system
    4. Unwinding tension 150 N for beam with flange diameter 1250 mm
    5. 160 N for beam with flange diameter 1000 mm at the air pressure of 6 bar
    6. Ferber beam-loading-unloading carrier with on-floor rails
    7. 2 electronic drafting force measuring systems model MW
  6. Water Pre-Wetting Tank
    1. Feeding group with 1 stainless steel cylinder
    2. 1 rubber-covered cylinder
    3. 1 chromed cylinder
    4. 2 sections tank
    5. Max. water temperature 90 °C
    6. Each section capacity 300 L
    7. Squeezing system at the exit of each section
  7. Benninger Size Boxes
    1. Model TD
    2. Cylinders width: 2400 mm
    3. Working width: 2200 mm
    4. Each box with 2 pairs of squeezing cylinders and 1 immersion cylinder
    5. Adjustable squeezing pressure up to 5.000 daN (kgf)
    6. Pneumatic device for pressure and lifting of the cylinder
    7. Automatic regulation of squeezing pressure by Ben-Sizetec system
    8. Automatic size feeding device
    9. Handymat sizing box control system with display
    10. Wet separating field for impregnating box for separation of the warp in two layers, with 1 Teflon-covered steam-heated measuring cylinder and 1 Teflon-covered steam-heated deviating cylinder
  8. Benninger Compact Dryer
    1. Type CT4/4/6
    2. 14 drying cylinders width 2400 mm (4+4+6), 10 of them Tefloned, diameter 800 mm
    3. Saturated steam 3.5 bar, max. temperature 147 °C
    4. 5 electronic temperature regulations; command by means of 3 phases motor and inverter
    5. Standard hooder with 2 fans
    6. CV oiling and waxing device at the exit
    7. Mahlo humidity control and regulation
    8. Dust suction and filtering system
    9. Dry separating field 6.5 meters length, with 19 chromed leasing positions
  9. Benninger High Productive Headstock/Beaming
    1. Model BB
    2. Width: 4600 mm
    3. Max. working width: 4000 mm
    4. Suitable for beams up to max. flange diameter 1100 mm
    5. Speed from 0.4 to 125 m/min
    6. Chain tension 1500 daN
    7. Inverter control
    8. Extensible reed
    9. Computerized microprocessor automatic control system, PC and modem
    10. Siemens Simatic PC FI15 software with monitor
  10. Size Kitchen
    1. Model: Sizemeix 1200
    2. Capacity 1400 L
    3. Working capacity: 1200 L
    4. With automatic temperature regulation system
    5. Water counter
  11. Storage Tanks
    1. 2 storage tanks model V1300
    2. Working capacity: 1300 L each, 1000 L capacity each
    3. Temperature regulation
  12. Condition
    1. Subject to availability
    2. Pictures available
