Trutzschler, Marzoli, Rieter, Complete Open End Spinning Plant, 10000-11000 kg Daily Capacity

Trutzschler, Marzoli, Rieter, Complete Open End Spinning Plant, 10000-11000 kg Daily Capacity

Description

  1. Overview
    1. Trutzschler blowroom line, year range 1998-2004, with 22 ton daily capacity and double feeding capability.
    2. Six Trutzschler DK803 cards with automatic can changing system.
    3. Four Marzoli C4 cards from 1996.
    4. Two Rieter RSB D 35 draw frames from 2004.
    5. Two Rieter SB D 15 draw frames from 2004.
    6. Yarn autoclave from 2004, computerized and fully automatic.
    7. Uster Premier lab from 2004.
    8. Marzoli combers with 3,500 kg per day capacity.
    9. Rieter draw frames plus Vouk draw frames with 20,000 kg per day capacity.
    10. Total spindles: 21,282.
  2. Capacity Specifications
    1. Based on Ne 20/1 yarn count.
    2. Daily blowroom capacity: 26,000 kg.
    3. Daily carding capacity: 10,000 kg.
    4. Daily draw frame and roving frame capacity: 17,000 kg to 22,000 kg.
    5. Daily ring frame capacity: 12,000 kg.
    6. General daily capacity: 10,000 to 11,000 kg.
    7. Additional cards and winders may be needed depending on the yarn counts run.
    8. Depending on speed, blowroom and carding capacity can be increased up to 700 kg per hour, 15,750 kg per day.
  3. Blowroom Equipment Details
    1. Machine 1: Trutzschler BDT 019, model 019-61 05, serial 122266, year 1996.
    2. Machine 2: Trutzschler BOA 1600, model 046-10-61, serial 122273, year 1996.
    3. Machine 3: Trutzschler CL-P, model 532504, serial 195494, year 2004.
    4. Machine 4: Trutzschler STAEMD BR-CO, model 9370401, serial 195492, year 2004.
    5. Machine 5: Trutzschler AFC, model 052-25 02, serial 122276-00, year 1996.
    6. Machine 6: Trutzschler EMA 1200, model 1520703, serial 12270, year 1996.
    7. Machine 7: Trutzschler BS 987 / 1600, model 987-10 02, serial 122282 B, year 1996.
    8. Machine 8: Trutzschler CVT 1, model 097-10-05, serial 122283 A, year 1996.
    9. Machine 9: Trutzschler BS 987 / 1600, model 987-10 02, serial 122282 A, year 1996.
    10. Machine 10: Trutzschler CVT 1, model 097-10-05, serial 122283 B, year 1996.
    11. Machine 11: Trutzschler MPM6 1600, model 236-10 06, serial 122278, year 1996.
    12. Machine 12: Trutzschler TV 425, model 106-00 32, serial 122286, year 1996.
    13. Machine 13: Trutzschler ASTA 800, model 151-03 01, serial 122275, year 1996.
    14. Machine 14: Trutzschler MCM6 1600, model 236-10 11, serial 122287 B, year 1996.
    15. Machine 15: Trutzschler MCM6 1600, model 236-10 11, serial 122287 A, year 1996.
    16. Machine 16: Trutzschler TV 425, model 106-00 31, serial 122277, year 1996.
    17. Machine 17: Trutzschler TV 425, model 106-00 31, serial 122285, year 1996.
    18. Machine 18: Trutzschler DX 385, model 385-10 05, serial 122293, year 1996.
    19. Machine 19: Trutzschler DX 385, model 385010 05, serial 122294, year 1996.
    20. Machine 20: Trutzschler CVT 4, model 971031, serial 122289A, year 1996.
    21. Machine 21: Trutzschler CVT 4, model 971031, serial 122289B, year 1996.
  4. Condition and Advantages
    1. Capacity advantage: blowroom and draw frame capacity of around 26,000 kg allows easy future capacity extension by adding extra cards, ring frames, and winders.
    2. Blowroom and carding double lot feeding: the blowroom has 2-way feeding and the card feeding system is adjusted accordingly, enabling simultaneous running of 2 types of fiber lots (e.g., high and low quality cotton, or mélange/blended yarn).
    3. Mélange and blended yarn manufacturing: the mill is prestigious for cotton-type mélange and blended yarn manufacturing as well as regular cotton yarn.
    4. Quality approved by Marks and Spencer, Next, Adidas, Puma, etc.; supplying to their suppliers for the last 10 years.
    5. Quality standards maintained through regular spare parts updates and periodic maintenance.
    6. Flexible system: the mill can run many types of blends simultaneously; spinning frames are short and manual type, making it easy to change yarn counts and blend types.
    7. Mélange and blended yarn manufacturing system setup is not easy but offers approximately 100% more profit than regular cotton yarn market.
    8. The investor can manufacture regular cotton yarn, mélange yarn, or blended yarn easily, and can run all three types simultaneously.
