Befama, Dilo, Needle Punched Fabrics Installation, 2500mm Working Width, 350 kg/h Capacity

Name: Befama, Dilo, Needle Punched Fabrics Installation, 2500mm Working Width, 350 kg/h Capacity
Brand: Befama / Dilo
SKU: G-3050
Availability: SoldOut

‹ Go Back Next Product ›

Sold

Description

Overview
1. Needle punched (bonded) fabrics installation line for rolls and panels production
2. Power of the line: ca 350 kg/h by PP/glas und PP/PES
3. Produced fabric weight per unit area: 300 to 2500 g/m²
Hopper Feeder
1. Hopper feeder with 2 separate chambers (variable partition wall)
Carding Machine With Opening Section
1. 1 piece for carding machine with opening section, working width 2500 mm
Crosslapper
1. 1 piece Befama crosslapper typ 5 W 32, working width 2500 mm (carding site) / 3200 mm (lay site)
Belt Conveyor
1. 1 piece belt conveyor to the pre needling machine
Pre Needling Machine
1. 1 piece pre needling machine Dilo 1, board approx. 3000 needles, working width: 2500 mm, needle direction from above
Finish Needle Machine
1. 1 piece finish needle machine Dilo 2, board approx. 6000 needles, working width: 2500 mm, needle direction from above
2. Rebuilt electronic drive controls with frequency converter
Cutting Machine
1. Longitudinal and cross cutting machine with compensating unit

Additional Specifications

HS code	8449.00

Specifications

Capacity	350 kg/h
Included	['Hopper feeder with 2 separate chambers', 'Befama Crosslapper Typ 5 W 32 (working width 2500 mm carding / 3200 mm lay)', 'Belt conveyor', 'Dilo Pre-Needling Machine (approx. 3000 needles, 2500 mm working width)', 'Dilo Finish Needle Machine (approx. 6000 needles, 2500 mm working width)', 'Longitudinal and cross cutting machine with compensating unit']
