NovaStar, RL108, PET Bottle Flake Washing Line, 500-700 kg/h, 380V 50Hz (New)

Name: NovaStar, RL108, PET Bottle Flake Washing Line, 500-700 kg/h, 380V 50Hz
Brand: NovaStar
SKU: G-3241

‹ Go Back Next Product ›

Description

Overview
1. Pet bottle flake washing line with a capacity of 500-700 kg/hr.
Line Components
1. Bale opener.
2. Label remover with 30 kW power, 1200-1500 kg/h capacity, dimensions 4538x2000x2954 mm, and a high pressure water pump of 7.5 kW.
3. Bottle sorting conveyor with 3 kW power, dimensions 1000x8000 mm, and an electric magnet.
4. Bottle conveyor with 1.5 kW power and dimensions 600x5000 mm.
5. Crusher with 30+3 kW power, 700-900 kg/h capacity, and a bottle pressing unit.
6. Screw conveyor with 3 kW power, 800-1000 kg/h capacity, and dimensions Φ 400x4000 mm.
7. Steam churn boiler with 7.5 kW power, 800-1000 kg/h capacity, and dimensions Φ 2000x2200 mm.
8. Discharger with 4 kW power, 800-1000 kg/h capacity, and dimensions Φ 400x5000 mm.
9. Frictional separator with 7.5 kW power, 800-1000 kg/h capacity, and dimensions Φ 600x4000 mm.
10. Sink and float tank with 4*2=8 kW power, 800-1000 kg/h capacity, dimensions Φ 400x5000 mm, and twin screw design.
11. Sink and float tank with 4*2=8 kW power, 800-1000 kg/h capacity, and twin screw design.
12. Spin dryer with 7.5 kW power, 800-1000 kg/h capacity, and dimensions Φ600x1400 mm.
13. Hot air dryer with 30+3 kW power, a stainless hopper of dimensions Φ1200X1500 mm.
14. Knife sharpener.
15. Electric panel with 3380V/50Hz power and mainly Siemens components.

Additional Specifications

Specifications

Capacity

500-700 kg/h

Included

['Bale Opener', 'Label Remover (30 kW, 1200-1500 kg/h, 4538x2000x2954mm)', 'Bottle Sorting Conveyor (3 kW, 1000x8000mm, with Electric Magnet)', 'Bottle Conveyor (1.5 kW, 600x5000mm)', 'Crusher (30+3 kW, 700-900 kg/h, with Bottle Pressing Unit)', 'Screw Conveyor (3 kW, 800-1000 kg/h, Φ 400x4000mm)', 'Steam Churn Boiler (7.5 kW, Φ 2000x2200mm)', 'Discharger (4 kW, Φ 400x5000mm)', 'Frictional Separator (7.5 kW, Φ 600x4000mm)', 'Sink and Float Tank (8 kW, Φ 400x5000mm, Twin Screw)', 'Sink and Float Tank (8 kW, Twin Screw)', 'Spin Dryer (7.5 kW, Φ 600x1400mm)', 'Hot Air Dryer (33 kW, Hopper Φ 1200x1500mm, Stainless Hopper)', 'Knife Sharpener', 'Electric Panel (mainly Siemens components)']
