Evergreen, Q-8830, Ultrasonic Quilting Machine, 84 Inches Working Width, 20 kHz, 12 Sets Ultrasonic Systems (New)

Evergreen, Q-8830, Ultrasonic Quilting Machine, 84 Inches Working Width, 20 kHz, 12 Sets Ultrasonic Systems

Description

  1. Overview
    1. Ultrasonic technology to weld and stitch the fabric together without needle or thread.
    2. High speed and high productivity, strong welding strength, stable quality.
    3. Different pattern roll can be ordered according to the clients different material and different product requirements.
    4. Typical applications: mattresses, bed sheets, seat cushions, snow jackets, car seat covers, etc.
  2. Machine 1: Model Q-6430
    1. Maximum working width: 60 inches
    2. Dimensions: L 6070 x W 2800 x H 2450
    3. Layers: 1 to 3 (plies)
    4. Variable working speed: 0 to 10 m/min
    5. Air required: 5 kg/cm (5 hp compressor)
    6. Frequency: 20 kHz (10 sets ultrasonic systems)
    7. Net weight: 2.2 tons
  3. Machine 2: Model Q-8830
    1. Maximum working width: 84 inches
    2. Dimensions: L 6070 x W 3320 x H 2450
    3. Layers: 1 to 3 (plies)
    4. Variable working speed: 0 to 10 m/min
    5. Air required: 5 kg/cm (5 hp compressor)
    6. Frequency: 20 kHz (12 sets ultrasonic systems)
    7. Net weight: 3.0 tons
