NovaStar, CR112, 4 Cylinders, 1000mm Wide, 300 to 500 kg/hr (New)

NovaStar, CR112, 4 Cylinders, 1000mm Wide, 300 to 500 kg/hr

Description

  1. One Opening Section
    1. Model: QK-500
    2. Diameter of cylinder: 500 mm
    3. Width of cylinder: 1000 mm
    4. Speed of cylinder: 1200 rpm
    5. Pin shape: U-shape
    6. Main motor: 15.8 kW
    7. Speed reducer motor: 1.5 kW
    8. Fan motor: 1.5 kW
    9. Feeding conveyor measurement: 1020 mm x 2800 mm
    10. Floor space dimension (L x W x H): 1800 mm x 1500 mm x 1200 mm
  2. Three Sections
    1. Model: QF-500
    2. Diameter of cylinder: 500 mm
    3. Width of cylinder: 1000 mm
    4. Speed of cylinder: 1200 rpm
    5. Main motor: 11 kW each section
    6. Speed reducer motor: 1.5 kW each section
    7. Fan motor: 3 kW each section
    8. Cylinder #2: 4.5 teeth per inch
    9. Cylinder #3: 6 teeth per inch
    10. Cylinder #4: 7 teeth per inch
    11. Floor space dimension (L x W x H): 2000 mm x 1500 mm x 1200 mm
