NovaStar, FG129, Box Mixing Tank for Foam, 180L Max Output, 35kW, 2 Moulds (New)

NovaStar, FG129, Box Mixing Tank for Foam, 180L Max Output, 35kW, 2 Moulds

Description

  1. Overview
    1. Material program: PPG, TDI, MC, SI, TIN, AN and water.
    2. Foaming density: 10 to 60 kg/m³.
    3. Max output: 180 liters.
    4. Mixing head power: 11 kW.
    5. Total power: 35 kW.
    6. Guarantee: CE certificate, maintain for one year.
    7. Reference number: G-5286-A.
  2. Capacities
    1. PPG: 3 m³.
    2. TDI: 2 m³.
    3. MC: 0.5 m³.
    4. Water: 1.0 m³.
    5. AN/TIN/SI: 0.05 m³.
  3. Tank Material
    1. PPG: steel.
    2. TDI/MC/water/AN/TIN/SI: stainless steel.
    3. PPG tank comes with agitator.
  4. Equipment Content
    1. Floor space size: 2300 mm x 700 mm x 2000 mm.
    2. Big material tanks: PPG-3 ton, 1 tank; TDI-2 ton, 1 tank.
    3. Small material tanks: MC-500 L, 1 tank; water, 100 L, 1 tank; small materials: 50 L, 3 tanks.
  5. Main Technical Specifications
    1. The software can store several different formulations with the automatic control mode.
    2. Can foam continuously (continuous working using two sets of moulds).
    3. Foaming chemicals are: PPG, TDI, MC, water, silicone, TIN, AN, material.
    4. Max foaming size: 2300 mm x 2000 mm; max foaming height: 1200 mm.
    5. Foaming density: 10 kg/m³ to 60 kg/m³.
    6. Max foaming output: 180 L each time.
    7. The motor power of mixing head: 7.5 kW (brake motor).
    8. Total power: about 30 kW.
  6. Material Tanks
    1. Big tank for PPG + mixing material: 3 m³ with constant temperature, mixing system, A3 steel; 1 tank.
    2. Big tank for TDI: 2 m³ with constant temperature, mixing system, stainless steel; 1 tank.
    3. Small tank for MCL: 500 liters, stainless steel; 1 tank.
    4. Small tank for water: 100 liters, stainless steel; 1 tank.
    5. Small tank material for A33, T9 small quantity: 50 liters, stainless steel; 3 tanks.
  7. Motors and Reducer Motors
    1. Motor (Siemens) 7.5 kW, reducer, gear pump, purpose mixing, quantity 1 pc, brand Siemens.
    2. Motor 0.75 kW/6P, gear pump HGP-2A-F3R, purpose H2O, quantity 1 set, brand Taiwan.
  8. Electrical Components
    1. Inverter for mixing: 11 kW, quantity 1 set, brand Siemens.
    2. Programmable controller/PLC: 6ES7214-2BD23-0XB0, quantity 1 set, brand Siemens.
    3. Interface monitor: 10.4 inch, quantity 1 set, brand Taiwan.
    4. Pneumatic 3 connecting executing valve, dish valve: 5" TDI, quantity 1 set, brand USA + Taiwan.
  9. Pneumatic Valves
    1. Pneumatic valve one 0.5" water.
    2. One 0.5" MC.
    3. One 0.25" silicone.
    4. One 0.25" AN.
    5. One 0.25" color.
    6. All electrical controls for pneumatic valves.
  10. Other Equipment
    1. Hydraulic pressure station: 2.2 kW/80 L.
    2. Hydraulic pressure vat: HOB100 x 250A, 1 set.
    3. Valves, flowmeter type: full set.
  11. Tubular Moulds
    1. E-6265 (2) tubular moulds: 1600 mm diameter x 2300 mm high with opening doors, quantity two.
  12. Foam Block Molding Machine
    1. Model: F-3.
    2. Hydraulic.
    3. 4 hydraulic cylinders: 63 mm diameter x 1500 mm long.
    4. 2 hydraulic cylinders: 63 mm diameter x 100 mm long.
    5. Total power for all 6 cylinders: 5.5 kW.
    6. Metal plate thickness: 1.5 mm.
    7. Plates are manually adjustable.
    8. Foaming size: 2550 to 3050 x 1550 to 2050 x 1200 mm.
    9. Including exhaust hood.
    10. Including control panel for moulding machine.
  13. Additional Information
    1. Full set of spare parts estimated needed for 1 year.
    2. Full set of mechanical and electrical diagrams.
    3. Plant block production: 24 to 40 blocks per 8-hour shift.
    4. Floorspace requirements: 5000 sq ft for machinery.
  14. Included Items
    1. Water chiller and water cooling tower.
    2. Connecting piping and all electrical wires within the machine.
    3. Total for machine, all holding tanks, main mixer and tanks, control system, electrical control panel, pumps and 3 moulds (2 tubular, one rectangular).
