Uster, Spinlab HVI 900-B, Fiber Testing Machine, 120/220 VAC, 90-100 PSI

Uster, Spinlab HVI 900-B, Fiber Testing Machine, 120/220 VAC, 90-100 PSI

Description

  1. Overview
    1. Uster Spinlab HVI-900-B fiber testing machine
    2. Device is in very good technical condition
    3. The device was under periodical service and supervision of service technician of Zellweger Uster Co.
  2. Length/Strength Cabinet
    1. Physical dimensions (measured from floor): 1370 mm x 980 mm x 80 mm
    2. 900 automatic: 347 kilograms
    3. 900 semi-automatic: 295 kilograms
  3. Micronaire/Color/Trash Cabinet
    1. Physical dimensions: 1070 mm x 980 mm x 800 mm; 190 kilograms
  4. Power Requirements
    1. 120 VAC, 50/60 Hz, 1080 watts
    2. 220 VAC, 50/60 Hz, 1080 watts
  5. Air Requirements
    1. Minimum 6.9 bar
  6. CRT Display
    1. 14-inch (360 mm) color screen, anti-glare face
    2. Resolution: 800 dots x 600 lines
    3. Character field: 2000 (80 x 25 lines)
    4. Dimensions: 359 x 356 x 395 mm (H x W x H)
  7. Force Transducer
    1. "S" beam full bridge type
    2. Linearity: 0.03% full scale
    3. Range: total load 100 lbs (45 kg); maximum overload 300 lbs (135 kg)
  8. Balance
    1. Electronic
    2. Weighing range: 310 g
    3. Readability: 0.01 g
    4. Reproducibility: 0.003 g (standard deviation)
  9. Pressure Transducer
    1. Very low differential pressure
    2. Accuracy: +1% full scale
    3. Range: ± 0-5 inches water column (± 0-130 mm)
  10. Lamps
    1. Incandescent
    2. Expected life: 1000 hours
  11. Available Accessories and Spare Parts
    1. Lamps for colour determination
  12. Calibration Means
    1. 2 x plates for colour determination
    2. 2 x sets of cottons for contamination determination
    3. Set of calibration cottons for HVI and for ICC
    4. 2 x length standard
    5. 1 x measuring of flow on micronaire module
