Benninger, Ben-Tronic, 2000, Sectional Warper, 3400mm Working Width

Benninger, Ben-Tronic, 2000, Sectional Warper, 3400mm Working Width

Description

  1. Spinning - Twisting
    1. Volkmann 2-for-1 twisting machine VTS-05 (3.01), year 1991, 2 x 24 spindles, 2 motors, delivery 10" traverse.
  2. Weaving Preparation
    1. Benninger Ergofronic electronic sectional warping machine, year 1993, useful working width 2000 mm, cone of the drum 1680 mm, max beam disc diameter 950 mm, with Benninger warp creel 2 x 8 x 40 = 640 ends, cone ratio 1:8, with pressure rollers and waxing system, tensioners disc type with central adjustment.
    2. Benninger Ben-Tronic electronic sectional warper, year 2000, useful working width 3400 mm, max beam disc diameter 1000 mm, with 2 warp creels pitch 280 mm (1 x 1200 ends and 1 x 800 ends).
    3. Sucker Muller sizing machine, year 1994, headstock "WN10" working width 3400 mm, beam disc diameter max 1000 mm, input creel for 16 primary warp beams 1800 mm, 1 sizebox SD40 + 1 sizebox SD-R useful working width 1800 mm roller width 2000 mm double dip double nip, dryer 10 cylinders for wet-split ZT2/2 year 2000 + 6 and extra dryer 6 cylinders, with size cooking equipment.
    4. K. Mayer direct warping machine, year 2007, type ZM-SP 1800 DNC, working width 1600 mm between the warp beam discs, maximum beam disc diameter 1000 mm, with pressure cylinder, with V-creel Benninger 56 x 8 x 2 = 896 ends, spindle distance 270 mm, with 2 cutting devices.
  3. Weaving
    1. 6 Sulzer G6200 rapier jacquard weaving machines, year 2000, with 2200 mm, 4 colours, each with 1 Staubli electronic jacquard machine CX860 format 1344 equipped 1290 hooks, year 1992, modules M4.2, controller JC4, 1 jacquard gantry for 2 looms, each with 1.5 warp beams 800 mm + 1.5 cloth rolls + 4 prefeeders.
    2. 4 Sulzer G6200 rapier jacquard weaving machines, year 2000, width 1700 mm, 4 colours, each with 1 Staubli electronic jacquard machine CX860 format 1344 equipped 1290 hooks, year 1991/1992, modules M4.2, controller JC4, 1 jacquard gantry for 2 looms, each with 1.5 warp beams 800 mm + 1.5 cloth rolls + 4 prefeeders.
    3. 6 Picanol Omni-4R-190 airjet weaving machines, year 1997, width 1900 mm, 4 colours, cotton type, electronic Staubli dobby 2580C equipped 16 shafts, electronic take-up, electronic let-off, 6 rows warp stop motion, accessories per machine: 16 heald frames + 3 prefeeders + 2 warp beams 1000 mm + 4000 heddles/droppers.
    4. 1 Dornier HTV4/SD - 210 rapier weaving machine, year 1991, width 2100 mm, 4 colours, mechanic dobby Stäubli 2232RS equipped 24 shafts, with 2 prefeeders + 2 warp beams 800 mm.
    5. 1 Dornier HTVS4/J - 160 rapier weaving machine, year 1996, width 1600 mm, 4 colours, with electronic jacquard machine Stäubli CX860 format 1344, with 4 prefeeders + 2 warp beams 1000 mm.
    6. 2 Dornier HTV4/SD - 280 rapier weaving machines, year 1989, width 2800 mm, 4 colours, electronic Staubli dobby 2660/28/28 equipped 28 shafts for max 24 heald frames + 4 colours, electronic let-off, mechanic take-up, 6 rows stop motion, max warp beam diameter 1000 mm, accessories each machine: 2 warp beams 800 mm + 2 prefeeders + 16 heald frames + 4500 heddles/droppers.
    7. 2 Dornier GTV4/SD - 300 rapier weaving machines, year 1986, width 3000 mm, 4 colours, mechanical dobby Staubli 2232S/20/20 equipped 20 shafts for max 16 frames + 4 colours, electric let-off, mechanic take-up, 6 row stop motion, max warp beam diameter 1000 mm, accessories per machine: 2 warp beams 800 mm + 2 prefeeders + 16 heald frames + 4500 heddles/droppers.
    8. 2 Sulzer Ruti G6200 B220 F8 J28 rapier weaving machines for terry, year 2004, working width 2200 mm, 8 colours, each with electronic jacquard machine Grosse format 5376, controllers C20, complete running machines with all standard accessories.
    9. 1 Sulzer Ruti G6200 B260 F8 J28 rapier weaving machine for terry, year 2000, working width 2600 mm, 8 colours, with electronic jacquard machine Grosse format 2688 hooks, controller C13, complete running machine with all standard accessories.
    10. 1 Sulzer Ruti G6200 B260 F8 SP rapier weaving machine for terry, year 2000, working width 2600 mm, 8 colours, with electronic jacquard machine Grosse format 1344 hooks, controller C13, complete running machine with all standard accessories.
    11. 2 Sulzer Ruti rapier weaving machines for terry, working width 2600 mm, 4 colours, complete running machines with all standard accessories, thereof 1 set G6200 B260 F4 SP QG1 year 1998 with electronic dobby and 1 set G6100 B260 F4 SP QG1 year 1992 with mechanical dobby.
    12. 2 Dornier HTV8/J - 320 rapier weaving machines, year 1997, nominal width 3200 mm, 8 ECS electronic colour selectors, Dornier controlbox AT1, each with Staubli jacquard machine CX880 format 2688 equipped 2400 - JC5 controller and modules M5, each with 1.5 warp beams 940 mm + 1.5 cloth rollers + 9600 droppers + 4 prefeeders, no gantry.
    13. 8 Dornier AWV8/S - 190 airjet weaving machines, year 2001, nominal width 1900 mm, panel AT2, 8 colours, electronic dobby Staubli 2871/16/12 equipped 12 shafts, electronic let-off and take-up, per loom: 4 prefeeders + 1.5 warp beams 1000 mm + 1.5 cloth beams + 6 heald frames + 5 warp stop bars + 5000 heddles/droppers.
    14. 4 Dornier HTVS8/S - 190 rapier weaving machines, year 1999, nominal width 1900 mm, 8 electronic colour selectors ECS, electronic Staubli dobby equipped 20 shafts, electronic let-off as well as take-up, panel AT2, accessories: each 12 heald frames + 6 prefeeders + 7500 heddles/droppers + 1.5 warp beams 800 mm + 2 cloth beams.
    15. 2 Dornier HTVS6/J - 190 rapier weaving machines, year 1997, working width 1900 mm, 6 colours E.C.S., control panel AT-1, each 1 Staubli jacquard machine CX-880 format 2688 equipped 2400 hooks, controllers JC4 (1997), modules M4.2, each with 1.5 warp beams 1000 mm + 1.5 cloth beams + 6 prefeeders + 1 gantry per 2 looms.
    16. 1 Kohl beam truck, year 2004, condition as new, hydraulic/electric system with battery-loader, max lift height 2.5 meter, max beam disc diameter 1000 mm, max beam width 3.3 meter, force 2000 kg.
    17. 2 Dornier HTVS/6J - 210 rapier weaving machines, year 1996, working width 2100 mm, 6 colours E.C.S., controlbox AT-1, each 1 Bonas jacquard machine CSJ format 2688 equipped 2400 hooks - year 2001/2002 - controller S500, each with 1.5 warp beams 1000 mm + 1.5 cloth beams + 6 prefeeders.
    18. 1 Dornier HTV6/J - 330 rapier weaving machine, year 1994, working width 3300 mm, 6 colours E.C.S., AT-1, with Staubli jacquard machine LX-1600.
