Description Overview Fabric width: 60", 68", 72", 76" (1530 mm, 1730 mm, 1830 mm, 1930 mm; other sizes made to order) Width reduction: min 4" (100 mm) and max 20" (500 mm) Standard performance up to 230 rpm or 380 meters/min weft insertion rate Yarns: filament, spun, mono, silk, flat, jari, viscose, bemberg, slub, catonic, roto, pp, nylon, acrylic, glass fiber, industrial yarns Weft Specifications Weft selector: up to 6 colours (electronic or mechanical) Weft yarns: spun ne 8 to ne80, filament 20 dtex to 900 dtex Weft density: 10 to 180 picks/inch, 4 to 70 picks/cm Weft insertion: flexible rapier tape with velvet sliding rapier heads Weft feeders: electronically controlled Weft cutter: mechanical cam drive Weft stop motion: piezo-electric with instant stop Shedding and Warp Shedding: tappet/plain, cam motion Top-mounted 16 jack mechanical dobby 600/1200 hooks mechanical jacquard Warp beam: single warp beam with 600 mm diameter (powerloom type) Warp let-off: mechanically synchronised with takeup with overtension switch (optical) Cloth Take-Up and Drive Cloth take-up: 7-wheel and 5-roll with 3-emery rolls mechanical takeup with easy doffing arrangement (400 mm diameter) Main drive: high-torque break motor, with single pick forward and reverse Sley drive: positive crank drive (korean type) Selvedge cutter: mechanically driven Lubrication and Control Lubrication: forced centralised lubrication Control system: forward, reverse pick, start and stop button, led lamp signal, production meter, usb port (optional)
