The pre-opener is shark-fin vertical plates type of cylinder clothing; the main opener is wire type of cylinder clothing with blowers to deliver cotton, magnet to remove metal scraps. Photoelectrical control.
GM-170 feeder (1 set)
Machine width: 1700 mm
Output: 100 to 250 kg/h
Total power: 5.2 kW
Dual photoelectrical quantitative controlled plus oscillating plate. The first photoelectrical sensor controls cotton transportation. The second photoelectrical sensor controls and the oscillating plate control density and uniformity of fabric distributing.
SL-185 single-cylinder garnett (1 set)
Machine width: 1850 mm
Dia. of main cylinder: φ1230 mm
Output: 80-250 kg/h
Dia. of doffer: φ500 mm
Circular runout of cylinder: ≤0.05 mm
Line speed: ≤40 m/min
Total power: 14.7 kW
Suitable for 2.5D-10D×38-75 chemical fibers such as polyester, polypropylene, nylon, etc. Single cylinder, double doffer. All rollers are specifically processed. Cylinder clothing is best brand. Inverter controlled cotton feed. Roller stripper and feeder fixed with metal prevention device.
PW-300 crosslapper (1 set)
Width of outlet apron: 3000 mm
Speed of outlet apron: 4-15 m/min
Lapping speed: 20 to 45 m/min
Speed of reciprocating apron: 20 to 45 m/min
≤5%
Total power: 8.2 kW
All transmission parts are made of lightweight and high strength materials. Subsection control improves web quality. Inverter controlled reciprocating movement.
HG-300 oven (1 set)
Oven length: 8000 mm
Oven width: 3000 mm
Inner temp.: 120 to 200 °C
Line speed: 6-18 m/min
Total power: 62.2 kW
It is capable to make both polyester wadding and non-glue pad products. For polyester wadding, apply top and bottom latex spraying. Three-layer drying zones, hot air convection. Top air blowing and bottom absorbing. Six blowers, locker type air track. Latex spraying hopper is by double water spray with stainless steel unit. Inverter controlled top and bottom spraying. For non-glue pad production, the top, middle and bottom layers are separated by insulation board. The blowers can be turned off.
XT-300 lengthwise and crosscut slitter (1 set)
Photoelectrical control
Digit meter-counter
Automatic alarm to stop running
Three blades controlled by air cylinder
Resistance wire cylinder crosscut
Total power: 1.5 kW
Speed adjustable
Buyer-Prepared Parts
Air compressor: 0.7 m³/min
Installed power capacity: 80 to 100 kW
Off-line pipes, cables and machine foundation
