Description Overview Speed: 5 to 55 m/min Three chambers (standard machine has 6 chambers) Double-fabric feed Distance from fabric feed to exit: 8410 mm Fabric capacity: 18 meters Oil heated Oil temperature: 200 °C Chamber temperatures: 100 to 135 °C Temperature accuracy: ±4 °C (at same cross section) Evaporation rate: 300 kg H₂O/hour Air nozzle type: up-and-down blowing motion Air blowing speed: 18 m/sec Air blowing rate: about 2600 m³/h Thickness of insulation plates: 75 mm Specifications Recycling blower: Y-132M-4, 75 kW Fabric feed motor: 0.75 kW Fabric draw-out motor: 0.75 kW Drawing-out tension is adjustable Machine dimensions: (L) (no. of chambers (3) × 1500 mm + 4095 mm) × (W) 3987 mm × (H) 3765 mm Machine shipping: two 40-foot containers Included Components Fabric feed entrance unit Oven (3 chambers) Exhaust discharging system Exit unit Fabric drawing-out unit Conveyor belt system Each heat zone has a heat exchanger, for a total of 3 heat exchangers Has 2 auto temperature controllers Spare Parts List 4 bearings for main blower 2 temperature controllers 1 set of installation tool 1 roll of granulated-surface rubber conveyor Electrical buttons Condition and Warranty Quality guarantee period: 1 year, free of charge for machine parts but not for artificial damage Machine installation: 12 to 15 days, buyer should pay for air tickets, transportation, and accommodation fees
