NovaStar, FG138, Manual Vertical Foaming Machine, 180kg Max Output, 15kW, 210L Mix Tank (New)

NovaStar, FG138, Manual Vertical Foaming Machine, 180kg Max Output, 15kW, 210L Mix Tank

Description

  1. Overview
    1. Impeller type mixer
    2. Maximum output: 180 kg
    3. Mixing speed: 0 to 2800 rpm
    4. Power: 15 kW
    5. Machine weight: 850 kg
    6. Machine external dimensions: (L) 1380 mm x (W) 940 mm x (H) 3050 mm
    7. Overall dimensions: 1400 mm x 1000 mm x 3050 mm H
    8. Overall height of unit: 3 meters
  2. Tank Specifications
    1. Tank dimensions: Ø 600 x (height) 750 mm, 2 pieces
    2. Tank sits on the floor
    3. Stainless steel 201, wall thickness 3 mm
    4. Tank capacity: 210 kg (210 liters)
    5. Usable capacity: 180 kg (190 liters)
    6. Main shaft diameter: 45 mm
  3. Included Accessories
    1. Spare parts: 1 set of maintenance tools
  4. Certification and Warranty
    1. Guarantee: CE certificate, one year guarantee
    2. Construction time: 45 workdays
