NovaStar, BT101, New, 1,500,000 kcal, 1800kW, Natural Gas-Fired (New)

NovaStar, BT101, New, 1,500,000 kcal, 1800kW, Natural Gas-Fired

Description

  1. Overview
    1. Heater body capacity: 1800 kW
    2. Burner: Ebico, natural gas-fired – 1,700,000 kcal/hour
    3. Four motors total
  2. Pumps
    1. Circulation pumps (2): 100 m³ per hour, 70 m, 30 kW, one for standby
    2. Oil feed pump (1): 2.2 kW
  3. Filtration and Separation
    1. 2 Y-type oil filters
    2. Oil-gas separator
    3. Y-type filter, model ZG1”
  4. Tanks
    1. Expansion tank, capacity: 2 m³
    2. Oil storage tank, capacity: 4 m³
  5. Motors
    1. Fan motor for burner: 7.5 kW
    2. 2 pump motors: 30 kW (1 is for standby)
    3. Feed pump motor: 2.2 kW
  6. Instrument Control System
    1. Cabinet
    2. Temperature meter
    3. Pressure gauge
    4. Temperature meter nozzle
    5. Pt thermal resistance nozzle
    6. Cushioning tube nozzle
    7. Pressure meter stop valve
  7. Included
    1. Quality certification of the heater body
  8. Specifications
    1. Capacity: 1,500,000 kcal (1800kW)
    2. Shipping reQuirement: 2x 40ft containers
