Description Overview 100-ton manual 4-post press with mechanical stops Pneumatic die rails Inboard and outboard motorized pinch roll Inboard and outboard 118” (3 m) long rough surface conveyor belt Inboard and outboard safety guards Pad shifter on top of steel plate Hardened and ground steel plate 1 hp servo motor positioning system Photocell for activation of first stroke Adjustable material side guide Manual adjustable device for cutting pad and steel plate Touch screen operator Double pumps and motors to increase cutting speed Specifications Machine bed: 35.4” depth x 59.1” width (900 x 1500 mm) Cutting stroke: 7.1” (180 mm) Tonnage: 100 tons Dimensions: 7052 x 2562 mm (278” x 101”, 23.1 ft x 8.41 ft) Condition Status: stopped, disconnected from power for company relocation to new building In excellent condition Exact age of the belt unknown but it is in excellent condition Machine does not cut against the belt Included Manual 4-post mechanical stops Pneumatic die rails Inboard and outboard motorized pinch roll Inboard and outboard 118” (3 m) long rough surface conveyor belt Inboard and outboard safety guards Pad shifter on top of steel plate Hardened and ground steel plate 1 hp servo motor positioning system Photocell for activation of first stroke Adjustable material side guide Manual adjustable device for cutting pad and steel plate Touch screen operator Double pumps and motors to increase cutting speed
