NovaStar, SA-PM, Auto Punching Machine, Working Width 2100mm, Working Height 200mm (New)

NovaStar, SA-PM, Auto Punching Machine, Working Width 2100mm, Working Height 200mm

Description

  1. Overview
    1. Working height: 8 inches
    2. Working width: 2100 mm
    3. Working speed: depends on foam material used, size of sheet, numbers of holes, pattern of die mold, etc.
    4. Working speed for sheet length of 2000 mm (leaving the front blank 125 mm, leaving rear blank 125 mm), the die mold is 2 rows, punching 18 times, from sheet in to feed out: approximately 108 seconds
  2. Specifications
    1. Loading conveyor: 2200 mm x 1600 mm
    2. Unloading conveyor: 2200 mm x 1600 mm
    3. Motor: AC: 15 hp x 1, 3 hp x 1, 1/2 hp x 2
    4. Servo: 1 hp x 2
    5. Row to row punching distance can be preset
    6. PLC man machine interface monitor: 10 inches
    7. Built to comply with CE electrical standards
    8. Working height: 200mm (8 inches)
  3. Operation and Tooling
    1. Replace new die when changes side to side distance
    2. Replace new die when changes hole shape
    3. Options: one round die tool (diameter 8 mm)
    4. Die punch lifespan: at least 3 years depending on material being punched and the frequency of use (this may change for higher use)
  4. Condition and Lifespan
    1. Machine lifespan: at least 10 years
    2. Warranty: 1 year from date of installation or 1.5 years after shipment from manufacturer (warranty excludes any defects caused by misuse/abuse of the machine, natural disaster-caused damages, damages caused by unauthorized modification, damage caused by improper storage of the machined and any parts which are worn out by the passing of time)
    3. We have been producing this machine for 10 years
