Description Overview 3.5 kw air cooled spindle Working area: 1300 x 2500 x 400 mm 4th rotary axis diameter: 600 mm 4th rotary axis length: 2000 mm Reposition accuracy: +/- 0.05 mm X, y and z working accuracy < 0.02 mm Tool diameter: Φ3.175 – Φ12.7 Collet size: ER 32 Operating language: G code (plt, mmg, uoo, bmp) Axis And Drive System X, y and z axis with taiwanese square linear guide rail X and y axis gear wheel (rack and pinion) transmission Y axis double motor drive Z axis imported ball screw, high precision Drive system: high quality stepper motor and stepper driver Driving system: 4-axis dsp control system Electrical And Control Fuling inverter Powermill software/artcam software/type 3 software/ ucancamv8 Working voltage: 220 volts, 1-phase, 50 or 60 hz (as per customer) Z-axis 0 sensor Limit switch for x, y and z axis Table And Construction Clamp table Working height: 200 mm Table surface: clamp & t-slot Constructed of welded steel Performance Specifications Travelling speed: 15 to 30 meters per minute Working speed: 10 to 25 meters per minute Maximum spindle speed: 24,000 rpm Operating environment: temperature: 0°c-45°c; relative humidity: 30%-75%
