Description Overview For feather/down and fiber cotton mix For filling toys, duvets, pillows and cushions With 2 nozzles For raw materials 50 to 95% feather down/fiber cotton Capacity: 4 kgs per minute per nozzle (240 kg per hour) Specifications Cycles: single port 2 scales cycle Filling speed (500 grams per chamber): 3 to 5 seconds Filling weight range (single time): 10 to 1200 grams Accuracy: 0.01 grams Independent operating system, up to 4 systems can be operated individually Power supply: 480 volts, 60 or 50 Hz (or as per clients need) Total power: 12 kW Air compressor power required: >/= 15 kW Working pressure: 0.6 to 0.8 Mpa Weight: 776 Dimensions and Weight Main mixing box dimensions: 2200mm length x 900mm width x 2250mm height Weighing box dimensions: 2200mm length x 900mm width x 1600mm height Total floorspace: >12 square meters Mixing box weight: 412 kg Weighing box weight: 364 kg Shipping First crate: 2230 x 930 x 2280mm, 425 kg Second crate: 2230 x 930 x 1630mm, 375 kg
