Description Overview Capacity: 120 to 220 pieces per minute Product size (unfolded): length 120 to 260mm x width 150 to 200mm Produce size (folded): length 60 to 130mm x width 50 to 80mm Control system: PLC control system, color touch screen Suitable materials: spunlace nonwoven fabric Weight of raw material: 35 to 80 gsm Size of raw material: width 150 to 200mm x diameter 1200mm Tank size: 800mm diameter x 2000mm height Tank volume: 400 liters Weight of machine: 2000 kg Machine dimensions: 5500mm length x 1000mm width x 2030mm height Electrical requirements: 480 volts, 60 Hz (or as per customer requirement) Total power: 6 kW Production Process Unrolling of raw material from parent roll Longitudinal folding Wetting of wipes Adjust humidity of wipes Cutting of wipes Cross-folding wipes Conveying of wet wipes to packing system Unrolling of packing film roll Printing of date on film Feeding of wet wipes and forming of bags Center sealing bags End sealing bags Output of finished products Sorting into piles Features Automatically counts pieces and sorts into piles; counting quantity can be directly adjusted on the color touch screen Automatically eliminates empty packs Width guidance system to place the material in the proper position Automatically stops when raw material is consumed Shipping Requires one 20 foot container to ship Packed for shipment in 3 wooden cases: 2860 x 1150 x 1900mm, 2860 x 1150 x 2150mm, 1000 x 1000 x 1850mm Total weight of all 3 wooden cases: 2500 kg
