Description Standard Accessories Main motor: AC 7.5 HP x 6P inverter control, 1 set, Siemens Width setting: servo motor driven, 1 set Cutter stand: ball spline, 2 pieces, Taiwan PMI; ball screw, 1 piece, Taiwan PMI Cooling system: automatic water supply, 1 set Cutting shaft: for paper core id 3”, 1 piece, Taiwan Xiangsheng Shaft sleeve: PE tube 76.2 mm (spare), 4 pieces Circular blade: 4 mm x 1” id x 750 mm od (c-type), maximum cutting od 650 mm, 1 piece Knife holding plate: 120/200, 1 set Knife motor: AC 7.5 HP x 4P inverter control, 1 set, Siemens Knife angle adjustment: angle change by servo motor drive, +/- 8 degrees, 1 set Shaft ending rack: automatic control, 1 set Cutting system: servo motor driven, 1 set Sharpening device: grinding knife at both levels, 1 set Maintenance kit: tools & instructions, 1 set Safety cover: connected, complete guard, 1 set Electrical Section Control system: PLC 3 servo motor system, 1 set, Japan’s Mitsubishi; 20 sets of widths settings, 1 set; automatic error detection system, 1 set Display mode: touch panel screen, 1 set, Japan’s Fuji Dimensions And Weight Dimensions: 3600 mm length x 1900 mm width x 1600 mm height Net weight: 2400 kgs Gross weight: 2600 kgs Total power: 13.0 kW SpecificationsVoltage: 220V 60HzCapacity: Cutting width 3mm to 2000mm, Cutting diameter max 650mm
