NovaStar, DN107, Cutting Area 3000x2100mm, Cut Speed 300 to 1000mm/s, Single Head (New)

NovaStar, DN107, Cutting Area 3000x2100mm, Cut Speed 300 to 1000mm/s, Single Head

Description

  1. Overview
    1. Single head cutting machine for corrugated board, plastic corrugated board, gray cardboard, pvc, foam board, pvc sheets, stickers, and more
    2. Cutting thickness: 50 mm maximum
    3. Cutting speed: 300 to 1000 mm per second (depending on material)
    4. Cutting area: 3000 x 2100 mm
    5. Feeding method: automatic
    6. Fix method: vacuum suction
  2. Specifications
    1. Repeat precision: 0.01 mm
    2. Software resolution: 0.025
    3. Works with computer for quick data transmission, multi-page files at once
    4. Interface: ethernet port
    5. Buffer memory: 1 gigabyte, fast transmission for multi-page large files
    6. Command mode: hp-gl/gp-gl compatible format
    7. Control panel: 7 inch color touch screen
    8. External dimensions: 4400 x 2900 x 1350 mm
    9. Voltage: 480 volts, 60 hz
  3. Included
    1. One head with 2 tools: oscillating tool and creasing wheel tool
  4. Options
    1. Pneumatic oscillating tool for cutting high density materials
    2. Milling tool for cutting high density materials such as acrylic and pvc
    3. Foam cut tool for cutting foam board, maximum thickness 50 mm
    4. Driving rotary tool for cutting fabric, textile
