Siemens, SGT400, 2013, 12.9 MW, Dual Shaft, Natural Gas, 50 Hz

Siemens, SGT400, 2013, 12.9 MW, Dual Shaft, Natural Gas, 50 Hz Sold

Description

  1. Overview
    1. Dual shaft
    2. Year: 2013
    3. Hours: 12000
  2. Specifications
    1. Power output: 12.9 MW
    2. Frequency: 50 Hz
    3. Voltage: 10.5 kV
    4. Generating power: 12.90 MV(e)
    5. Fuel: natural gas
    6. Power generation efficiency: 34.8%
    7. Heat consumption: 10.355 kJ/kW-hr (9.815 BTU/kW-hr)
    8. Turbine speed: 9,500 rpm
    9. Compressor pressure ratio: 16.81
    10. Exhaust flow/temperature: 39.4 kg/s 555 °C (86.8 lb/s 1031 °F)
    11. NOx emission (DLE converted to 15% O2 dry type): <25 ppmv
  3. Scope Of Supply
    1. Generator set
    2. Control system
    3. Inlet cabinet
    4. Output cabinet
    5. PT cabinet
