Dimensions: 3600 mm length x 2450 mm width x 1680 mm height
220 volts, 60 Hz
Operational Features
The machine die is installed on the bottom of the upper punching plate
Automatic feed motors, PLC controlled
With push button operated shuttle table
PLC integrated touch screen monitor
Press activated only when shuttle table is in position
Machine has been analyzed to be energy efficient and to optimize its energy use, reducing operational costs for the customer
Safety Features
Includes eye sensors in front and back of press and guards on the side with safety switches
All safety devices will be double checked and improved where necessary, including emergency stops, shields, guards, protection signage as per American standards
Included Items
One set of PLC spare included
One set of miscellaneous electrical parts included (such as relays, contactors, fuses, overload controls, etc.), enough for two years supply
Comprehensive operator manual included in simple English language for machine operation and safety instructions
Production Notes
Stroke capability of 200 mm, customizable up to 250 mm for enhanced flexibility in operations
Minimum die height requirement is 15 mm, accommodating a wide range of tool sizes for various tasks
The die is not fixed on the moving table, promoting longevity and precision by avoiding repetitive cuts in the same position
The machine features a cycle time of approximately 16 seconds for one complete cycle, including the shuttle moving under the pressing plate, the pressing cycle itself, and the shuttle returning to the home position. This ensures efficient production rates
