Description Overview 8 colors Max. printing width: 1200 mm Max. web width: 1250 mm Min. web width: 500 mm Min. repeat: 300 mm Max. repeat: 900 mm Repeat gap: 10 mm Max. mechanical speed: 300 m/min Nonstop un- and rewinding Max. reel diameter: 1000 mm Core inner diameter: 76 mm Max. reel weight: 1000 kg Compressed air consumption: 3.4 m³/hour with electronic ink pumping Printing inks (lacquer): flexoprinting solvent Printing desks mounting: 1.14 + 0.55 mm Input: 231 kVA Dimensions And Weight Overall dimensions (w x l x h): 5990 x 18050 x 5650 mm Weight: approx. 55,000 kg Printing Unit Printing unit with a central drum Remote control of the inking units with step motors Closed chamber blade system with ceramic anilox rollers Drying Unit 2 closed circulation systems, thermo- and soundproof, energy-saving (main drying tunnel and heating heads between the inking units) Enables to be connected to catalytic incinerator Cooling Unit Cooling unit Lifting Unit – Nonstop (2) electrical pully with motoric traversing (2) lifting tables for reel loading and unloading Machine Drives Asynchronous motors Equipped With (1) web guide before printing and before rewinding (1 control unit) (1) printing inspection system Fife Invista (1) antistatic unit applied on rewound reel (2) rollers before printing and rewinding (1) automatic viscosity control (1) corona Softal
