Jacob Muller, NF, 6 Heads, 42mm Reed Width, Parallel Reed Action, 1.5 kW

Jacob Muller, NF, 6 Heads, 42mm Reed Width, Parallel Reed Action, 1.5 kW

Description

  1. Overview
    1. Six needle heads per machine
    2. Weaving system: II+III
    3. Parallel reed action
    4. Nf regulator
  2. Specifications
    1. Maximum reed width: 42 mm
    2. Ribbon width: approximately 40 mm maximum
    3. Weft density: (3) 8-40 weft density per cm
    4. Weft transport: mutrans2, all wefts with mutrans transport
    5. Sheding: Q20
    6. Normal shedding size
    7. Chain design shaft movement
  3. Electrical
    1. Electric motor: 1.5 kW / 1500 min-1
    2. Electrical connection: 3 x 220 V, 60 Hz, without neutral
