Description Overview One size box Creel holds up to 12 beams from warping Specifications Maximum feed beam diameter: 1000 mm Maximum feed beam width: 1800 mm One sizing box with 2 squeezers and 2 submersible cylinders with a width of 2000 mm 12 drying cylinders with 800 mm diameter and 2000 mm wide; five of them are teflon coated 150 m/min working speed (depends on the yarn type) Malho speed regulator and residual moisture control Preparation kitchen that holds 650 liters and a reserve tank Maximum width of exit head end: 2850 mm Maximum diameter of warp beam flange: 1250 mm Condition Pictures available upon request
