Jakob Muller, MDK 80 D, Double Needle Bed Warp Knitting Machine, 800mm Usable Width, 24 NPI, 2 Beds

Jakob Muller, MDK 80 D, Double Needle Bed Warp Knitting Machine, 800mm Usable Width, 24 NPI, 2 Beds

Description

  1. Overview
    1. Jakob Muller double needle bed warp knitting machine
    2. Model MDK 80 D
    3. Usable width: 800 mm
    4. 2 beds: D
  2. Needle Specifications
    1. Needles per inch: 24 / inch
    2. Total needles: 792
    3. 8 needle section
    4. Needle segment width: max. 25.4 mm
    5. "T" rail: > 10-25 mm
  3. Fabric Puller
    1. Fabric puller for: 3-20 maschen/cm
    2. Walzenbelag: Vulkollan
  4. Electrical Specifications
    1. Motors: 10 kW with electronic frequency converter
    2. Voltage: 3x400 V, 50 Hz with neutral conductor
    3. Power: 12 kW (2 or) / 22 kW
  5. Pneumatics
    1. Air pressure: 6 bar
