IDM, Model 5016, Hand-Held Particle Tester, 0.5 to 25.0um Size Range, 0.1 CFM Flow Rate, 3.5 Inch Color Touch Screen

Name: IDM, Model 5016, Hand-Held Particle Tester, 0.5 to 25.0um Size Range, 0.1 CFM Flow Rate, 3.5 Inch Color Touch Screen
Brand: IDM
SKU: L-1627

‹ Go Back Next Product ›

Description

Overview
1. The handheld 5016 particle counter features 0.5 µm sensitivity and is the most advanced handheld particle counter on the market.
2. Provides up to 6 particle size channels of simultaneous counting.
3. Can display cumulative and differential particle count data as well as temperature/relative humidity data on the fast and easy to read colour touch screen.
4. This unit can hold up to 3000 records of particle data and the configurable recipe database can store up to 50 recipes for sampling and reports.
5. Removable batteries and an optional charger help to maximize the handheld’s uptime.
6. Data is very easily downloaded using the data transfer software.
Features
1. 0.5 - 25 µm
2. Flow rate 0.1 cfm (2.83 lpm)
3. View 6 particle sizes simultaneously
4. Unit-to-unit accuracy and repeatability
5. Bright 3.5" (8.89 cm) colour touch screen display
6. Removable / rechargeable li-ion battery
7. Large memory for storing data (3,000 samples)
8. Concentration limit - 4,000,000/ft³
9. Temperature/relative humidity probe included
10. Test wizard for cleanroom pass/fail reports
11. FS-209E, ISO-14644-1 or EU GMP annex 1
12. 50-record recipe database
13. Interface with zoom capability
14. Open architecture connectivity with OPC server
15. Alphanumeric location labels
16. Internal audible alarm
17. Ergonomically designed
18. Lightweight
19. TFT colour touch screen interface
20. Removable rechargeable li-ion battery
Specifications
1. Size range 0.5 – 25.0 µm
2. Channel size standard: 0.3, 0.5, 1.0, 2.5, 5.0, 10.0 µm
3. Counting efficiency 50% @ 0.5 µm; 100% for particles > 0.75 µm (per ISO 21501-4)
4. Flow rate 0.1 cfm (2.83 lpm)
5. Zero count level <1 count / 5 minutes (per ISO 21501-4)
6. Concentration limits 4,000,000 particles/ft³ @ 5% coincidence loss
7. Calibration meets ISO 21501-4 calibration using NIST traceable PSL spheres, DMA and
8. Data storage 3,000 sample records, rotating buffer (includes particle and environmental data)
9. Communication modes RS-232 via RJ-45 to a PC or an optional printer
10. Supporting software LMS Express, LMS Express RT, LMS Pharma
11. Environmental sensors temperature/relative humidity probe: 32-122°F (0-50°C) +/- 1°F (0.5°C); 15-90%
12. Touch screen display 3.5" (8.89 cm), colour TFT
13. Reports FS-209E, ISO-14644-1 & EC GMP
14. Alarms internal, adjustable alarm buzzer. Alarms on counts, low battery or sensor
15. Sample inlet isokinetic sampling probe
16. Sample outlet internally filtered to HEPA standards (>99.97% @ 0.3 µm)
17. Enclosure high impact injection moulded plastic
18. Power external power supply: 12VDC, 1.25A
19. Battery li-ion, internal & rechargeable
20. Dimensions 8.75" (L) x 5.0" (W) x 2.5" (H) (22.23 x 12.7 x 6.35 cm)
21. Weight 2.2 lb (1 kg)
22. Languages English (U.S.), Deutsch, Espanol, Italiano, Francois, Russian, Japanese, Korean
Benefits
1. 2 year warranty
2. User friendly interface
3. International support
4. Low cost of ownership
