Automatic pneumatic controlled compression and decompression system with manual exhaust valve for emergency
Circulatory System
Equipped with an external heat exchanger (design pressure 10 bar), high efficiency centrifugal pump with motor, motor cover and stainless steel base
Filtering device with standby one set of additional filter tube
Equipped with automatic heating and cooling control system, steam trap
Average heating rate: 3.5 °C/min (steam working pressure 7 bar)
Average cooling rate: 2.5 °C/min (cold working pressure 3 bar)
Single inlet and drain off
Chemical Tank
Chemical tank, reflux stirring system, feeding system, automatic spray cleaning system
Controlling Cabinet
Converter controls the main pump
Isolating switch, fuse, motor and transformer starter
Full-functional microprocessor model YB868 and corresponding PLC programmable logic controller
The pneumatic control panel with pressure gauge, oil mist, air separator, pressure regulating valve and solenoid valve control, which is isolated from electricity controlling cabinet
Spare Parts List
Nozzle sealing ring: 2 pieces
Gasket for toughened glass: 2 pieces
Silicone gasket for lens: 2 pieces
Sealing ring for top flange: 2 pieces
Sealing ring for rear flange: 2 pieces
FKM oil seal: 2 pieces
O type sealing ring: 4 pieces
4 inch gasket for bellows: 10 pieces
6 inch gasket for bellows: 4 pieces
Belt: 2 pieces
Wrench: 1 piece
