NovaStar, GL154, Haze Tester, Sample Size 50x50mm, 220/240 VAC (New)

NovaStar, GL154, Haze Tester, Sample Size 50x50mm, 220/240 VAC

Description

  1. Overview
    1. The rk122 series haze meters are applicable in all transparent and semitransparent parallel level material for testing transmittance and haze degree.
    2. The GL154 unit adopts parallel lighting, hemispherical scattering, and integral ball photoelectric receiving modes.
    3. The microcomputer automatically controls the test and data processing system for convenient operation.
    4. The unit automatically displays the average value of transmittance/haze which is repeatedly measured.
    5. The instrument is not influenced by environmental light so a darkroom is not required.
    6. Standard usb data output interface supports a remote printer if required.
  2. Applications
    1. Plastic films
    2. Glass
  3. Features
    1. Led display
    2. Usb connection
    3. Sample area: 21 – 25 mm
    4. C clamp-house dc12v 50w tungsten halogen lamp + colour temperature sheet
    5. Receiver: silicon photocell + visual function correction sheet (v(λ) standard value)
    6. Accuracy: transmittance 0.1%
    7. Haze degree 0.01%
    8. Testing range: transmittance 0 – 100%
    9. Absolute haze degree 0 – 30%
    10. Relative haze degree 30% – 100%
    11. Sample size: 50 x 50 mm
    12. Tank size: 50 x 50 x 10 mm
    13. Automatic calibration
    14. Environmental conditions: 10 - 50°c
  4. Standards
    1. Gb2410-80
    2. Astm d1003-61
    3. Jis k7105-81
  5. Benefits
    1. Easy to use
    2. Fast measurement speed
    3. Accurate
  6. Connections
    1. Electrical: 220/240 vac @ 50 hz
  7. Dimensions
    1. Height: 300 mm
    2. Width: 740 mm
    3. Depth: 270 mm
    4. Weight: 21 kg
