Description Andritz Compadis Cd 12 Disperger Year: 2007 Used to break up fiber bundles and to mix in bleaching chemicals Nominal speed: 1500 rpm Nominal output: 250 tons per day Minimum flow: 100 t/d Maximum flow: 300 t/d Maximum operating temperature: 130 degrees c Maximum operating pressure: 3 bars No motor Actuating drive: approximately 4 kw Unit has an inlet screw but no motor Speed of the inlet screw should be approximately 525 rpm Unit has a plug screw feeder driven by a sew-euro drive 30 kw motor 240/480 volts Plug feeder has 22 inches x 16 inches feed through 14 inches diameter screw Reference number: P-6900 Voith Htd-3-P Disperger System Year: 1996 Type: htd-3-p Consists of: Stator 1117 mm diameter, rotor 1146 mm diameter With 1500 hp allis chalmers 4160 volt motor 1175 rpm Approximately 44 inches diameter x 30 feet stainless steel steam tube with (12) 2 inches steam ports 16 inches x 11 feet stainless steel conveyor Reference number: R-3668 Deinking Plant Capacity: 150 tpd Brightness: 80% Conventional pulper 18 m3 low density with belt conveyor Hdc comer model dpa30 flow 3.00 l/min 2 x beloit barrier screen holes basket + 1 spare screen Lamort ch7 screen slotted basket Low density cleaner section beloit 2 dilution pumps for the deinking cells 2 x deinking cells comer for primary treatment 1 x deinking cell comer for second treatment Lamort vertical screen sph12 with slotted basket Drum thickener for hot dispersion from the 0.8 to 5% Belt press comer from 5 to 30% Heater screw at 1.5 bar comer and disc disperger krima Bleaching tower Complete recovery water system Complete with: pipes, regulation (not all), pumps and control panels Reference number: R-3666 Paper Machine With Deinking Plant Trim (pope): 2200 mm Year: 1988, overhauled year 2013 Paper weight: 50 to 200 gr/m2 Speed: 250 m/min Production capacity: 30 to 60 ton/day Drive: variable frequency motors Quality control system: qcs honeywell (weight, humidity, color, brightness) Bridge crane: two hooks 2.5 ton each Year of installation in atlas: 1988 Overhauling 2013: new drive system, new size press, new head box, new qcs Product: printing and writing Stock prep and approach flow: Pulper: 12 m3 grubbens 1 disc refiner pilao de 20” 2 conical refiners, wolf Consistency control dezurik Centrifugal depurators celleco heavy 16 cones three stages Low density cleaners 26 cones in two stages Pressurized screen slots 0.2 mm voith Complete deinking plant: Pulper helical 4, lamort 8 m3 + 24 m3, inox, rotor grubbens, motor 200 hp Pump pulper gorman rup, 4000 l/min, power 40 hp Vibrating screen on inox, 5 mm, 2100 x 1170 mm holes 4 mm, 5 hp Tank 3 40 m3, concrete with agitator lightin, 15 hp Pump tank 3 hidrostal, 20 l/s, 20 hp Vibrating screen 1 inox, 5 mm, 2100 x 1170 mm, holes 4 mm, 5 hp Hdc escher wyss mod 1558, 5 hp Screen lamort, ch3, inox, 30 hp Level box 1600 x 620 x 840 mm, inox Water tank 15 m3, concrete Pump turo, tw7 125, 120 m3, 15 hp Deinking cell 1 lamort, 20 t/d, 8 m3, pl 4 mm, inox Deinking cell 2 lamort, 20 t/d, 8 m3, pl 4 mm inox Ventilator ventmeca, 20 hp, 3500 rpm Pump turo, tw7125, 120 m3/hr, 25 hp Pump goulds, mod 3196, 155 m3/hr, 25 hp Pump goulds, mod 3196, 155 m3/hr, 25 hp Pump crane, mod 3065 3265 120 m3/hr, 20 hp Tank 14 m3, concrete Pump goulds, mod 3196, 4000 l/min, 30 hp Vertical screen 2 black clawson, 50 mini screen, 30 hp Thickener 3.2 x 1.9 x 2.8 inox 7.8 hp, motor 10 hp Screw 5 hp, 1750 rpm Paper machine: Pressurized head box 101” black clawson Fourdrinier table, voith 5 foil stations 2 vacuum foils 6 high vacuum boxes Dandy roll Couch roll Vacuum system: nash pumps one, 500 cfm, three 1000 cfm and one 2000 cfm 1st and 2nd press, 200 pli, granite Pre-drying 18 cylinders bertram, 50” diameter and 2700 mm length Size press inclined rolls san quindao Post-drying 8 cylinders bertram 50” diameter and 2600 mm length Rope system Hydraulic calendar hunt moscrop, 3 nips Winder (pope) 8 shafts for pope rolls Reference number: R-3666
