NovaStar, QL193, Mechanical Shuttle Multi-Needle Quilting Machine, 64 Inch Width, 2 Needle Bars (New)

NovaStar, QL193, Mechanical Shuttle Multi-Needle Quilting Machine, 64 Inch Width, 2 Needle Bars

Description

  1. Configuration
    1. Cs64 – 2 rows of needles (2 needle bars) – 64 inches wide
    2. Model: 64-2
  2. Specifications
    1. Dimension (l x w x h): 3150 x 960 x 1560 mm
    2. Weight: 1500 kg
    3. Needle row distance: 1 - 2: 76.2 mm
    4. Needle row distance: 25.4 mm
    5. Saddle stroke: 101.6 mm (4)
    6. Quilting thickness: ≤30 mm
    7. Output: 20-120 m/h
    8. Needle no.: #16, #19
    9. Max needle qty: 128 pcs
    10. Quilting width: 1626 mm
