NovaStar, KH144, Interlock Circular Knitting Machine, 60" Diameter, 24 Gauge, 120 Feeds (New)

Description

Overview
1. Interlock machine
2. Cylinder: 60 in
3. 24 gauge
4. 120 feeds
5. 100% lycra
6. Groz needle and high standard equipment
Variations
1. Machine comes in 3 variations
2. Gauge distance: E18-E28, E30*, E32*, E40*
3. Feed: 2.1 feeds per inch (30 in machine 72 feeds), 2.5 feeds per inch (30 in machine 84 feeds)
Specifications
1. Linear speed: 1.4 meters per second
2. Floor area: 25 m²
3. Weight: 2,600 kg to 3,200 kg
Configuration Details
1. 2.5 feeds per inch, double knitting machine includes 2 track needle and 4 track needle on the cylinder; by changing the needle arrangement, configuration of the cam and needle, not only can produce jersey, rib, but also the production of double knit
2. 2.1 feeds per inch, double knitting machine; there are 2 dial track and 4 cylinder track, essentially suitable for rib fabric; can do 1+1, 2+2, and drop needle
Additional Information
1. More information is available upon request

HS code	8447.12

Capacity	60" diameter, 120 feeds
Gauge Distance Options	E18-E28, E30, E32, E40

Dimensions	Floor area: 25m2
Weight	3,200 kg

Gauge	24
Max speed	1.4 meters per second
