NovaStar, BR114, Pringles Potato Chip Production Line, 250 kg/h, 130 kW (New)

NovaStar, BR114, Pringles Potato Chip Production Line, 250 kg/h, 130 kW

Description

  1. Overview
    1. Total dimensions (excluding packing machine): 42 meters long x 6 meters wide x 4.5 meters tall
    2. Oil consumption: 25 kg per hour
    3. Fuel consumption: 25 to 30 cubic meters per hour
    4. Airflow rate: 1.2 cubic meters per minute
    5. 125 kW
    6. Requires 8 to 10 men to operate
    7. Frying machine length: 9.6 meters
    8. Requires five 40 foot containers
    9. Production capacity: 250 kg per hour
  2. Cone Mixer
    1. Main material: stainless steel 304
    2. Power: 4 kW
    3. Weight: 300 kg
    4. Mixing speed: 62 rpm
    5. Size: Φ1000 x 2000 mm
    6. Capacity: 0.3 m³
  3. Powder Feeder
    1. Size: 2000 x 2500 x 3000 mm (L x W x H)
    2. Weight: 100 kg
    3. Speed ratio: 17
    4. Transportation size: Ø130 x 600 mm
    5. Power: 1.87 kW
    6. Stainless steel
  4. Ration Powder Feeder
    1. Conveyor power: 0.37 kW
    2. Mix power: 0.75 kW
    3. Powder amount: 25 kg per time
    4. Size: 1100 x 550 x 1050 mm
    5. Weight: 50 kg
  5. Flour Mixer
    1. Transmission power: 11 kW, spindle speed is controlled by frequency conversion (25-30 Hz)
    2. Weight: 2000 kg
    3. Size: 1100 x 550 x 1050 mm
  6. Flattening Conveyor
    1. Power: 0.75 kW, speed: 0.5-0.7 m/min, weight: 500 kg
    2. Size: 2000 x 1300 x 470 mm (L x W x H)
    3. Conveyor belt adopts PU, specification: 5200 x 1050 mm
    4. The material of the machine adopts stainless steel
  7. Flattening Machine
    1. Power: 24.75 kW
    2. Flattening thickness: 0.8 mm
    3. Speed: 5-7 m/min variable frequency speed regulation, weight: 5000 kg
    4. Size: 1400 x 3900 x 2500 mm (L x W x H)
    5. Wallboard using 35# steel plate, diameter 100 mm pressure roller diameter 415 mm, materials use wear-resisting cans made pieces, centrifugal casting
    6. Shields shell, a cylinder, Samsung roller materials use stainless steel
  8. Water Cooling Refrigerator
    1. Power: 3.8 kW, weight: 600 kg
    2. Main material: stainless steel 304
    3. Size: 1650 x 1000 x 3000 mm (L x W x H)
    4. Standard cold quantity: 14800 calories/hr
  9. Forming Machine
    1. Weight: 1500 kg
    2. Size: 3400 x 1600 x 1750 mm (L x W x H)
    3. Power: 6.75 kW variable frequency speed regulation
    4. Conveyor belt adopts PU, specification: 8600 x 1050 mm
    5. Pressure roller diameter: Ø180 mm
    6. Single piece mold size: 66 x 46 mm
    7. Shields, conveyor girders material adopt stainless steel
  10. Material Crushing
    1. Power: 7.5 kW, weight: 400 kg
    2. Spindle speed: 4800 r/min
    3. Size: 1300 x 600 x 1400 mm (L x W x H)
    4. Hammer number: 8 group, sieving slice aperture Ø2.0 mm
    5. Hopper and shell material adopt stainless steel
  11. Back Material Conveyor
    1. Power: 0.37 kW x 5 sets, weight: 100-200 kg
    2. Main material: stainless steel 304
    3. Size: 2300 mm x 1 set, 6400 mm x 1 set, 5300 mm x 1 set, 2500 mm x 2
    4. Equipment bracket and the body adopt stainless steel
  12. With Water, Ingredients Barrel
    1. Power: 0.55 kW x 2
    2. Stirring speed: 84 rpm
    3. Weight: 400 kg
    4. Size: Ø680 x 1400 mm
    5. Equipment bracket and the body adopt stainless steel
  13. Freezer
    1. Weight: 100 kg
    2. Size: Ø680 x 1200 mm (L x W x H)
    3. Equipment bracket and the body adopt stainless steel
  14. Dough Making Water Refrigerator
    1. Power: 3.8 kW, type: KCB-50, weight: 500 kg
    2. Size: 2450 x 1100 x 1400 mm (L x W x H)
    3. Standard cold quantity: 12000 calories/hrs
    4. Equipment bracket and the body adopt stainless steel
  15. Salt Water Feeding Pump
    1. Power: 1.5 kW
    2. Pressure: 2.5 MPa
    3. The apertures of the inlet and the outlet pipes: 20 mm
    4. Flow: 1.08 m³
    5. Weight: 20 kg
    6. Equipment bracket and the body adopt stainless steel
  16. Mixing Wastewater Tank
    1. Capacity: 100 kg, weight: 20 kg
    2. Size: diameter 500 x 800 mm (L x W x H)
    3. Equipment bracket and the body adopt stainless steel
  17. Frying Machine
    1. Power: 16.2 kW
    2. Main material: stainless steel, axle and chain wheel material steel, weight: 5000 kg
    3. Size: 9700 x 2100 x 2300 mm (L x W x H)
    4. Mold number: 220 pieces
    5. Oil capacity: 1400 kg
    6. Net belt size: 2000 x 970 mm
    7. Fried effective length: 9 m
    8. Oil consumption amount: 30-33%
    9. Module size: 980 x 75 mm
    10. Equipment bracket and the body adopt stainless steel
  18. Filtering Machine
    1. Power: 0.55 kW
    2. Size: 1300 x 900 x 1800 mm (L x W x H)
    3. Equipment bracket and the body adopt stainless steel
  19. String Belt Conveyor
    1. Power: 0.55 kW, 1 23 x 1 set, weight: 350 kg
    2. Main material: stainless steel, size Ø6
    3. Size: 1650 x 1400 x 1200 mm (L x W x H)
    4. Equipment bracket and the body adopt stainless steel, the thickness is 1.5 mm
  20. Oil-Burning Boiler
    1. Power: 13 kW, weight: 3500 kg
    2. Size: 3000 x 1000 x 2800 mm (L x W x H)
    3. Oil consumption amount: ≤25 kg/h
    4. Heat: 200000 calories
    5. Equipment stents bake black paint, the body shell is stainless steel
  21. Oil Drum
    1. Oil capacity: 1400 kg, weight: 500 kg
    2. Main material: stainless steel
    3. Size: 1550 x 1550 x 2950 mm (L x W x H)
    4. Equipment bracket and the body adopt stainless steel
  22. Return Oil Cylinder
    1. Stents and barrel materials are stainless steel
  23. Oil Leach Conveyor
    1. Linear velocity: 0-16 m/min, weight: 200 kg
    2. Size: 1200 x 1400 x 1200 mm (L x W x H)
    3. Equipment bracket and the body adopt stainless steel
  24. Vibration Up
    1. Power: 0.37 kW x 2, weight: 400 kg
    2. Main material: stainless steel
    3. Size: 2000 x 850 x 1200 mm (L x W x H)
    4. Equipment bracket and the body adopt stainless steel
  25. Vibration Down
    1. Power: 0.37 kW x 2, weight: 400 kg
    2. Main material: stainless steel
    3. Size: 2000 x 700 x 650 mm (L x W x H)
    4. Equipment bracket and the body adopt stainless steel
  26. Flavoring Machine
    1. Power: 0.37 kW, speed ratio: 1 43, weight: 100 kg
    2. Main material: stainless steel
    3. Convey belt material is PU, size: 1760 x 150 x 1.2 mm
    4. Size: 1000 x 650 x 600 mm (L x W x H)
    5. Equipment bracket and the body adopt 3 mm stainless steel
  27. Cooling Conveyor
    1. Power: 0.55 kW, speed ratio: 1 43
    2. Weight: 600 kg, main material: stainless steel
    3. Size: 6200 x 1400 x 1050 mm (L x W x H)
    4. Convey belt material is PU, size: 12200 x 1180 x 1.5 mm
    5. Equipment bracket and the body adopt 4 mm stainless steel
  28. Platform (Step)
    1. Including all of the platform, step and escalator the equipment need
    2. Mixer and send powder platform
    3. Size: 2100 x 2100 x 1900 mm
    4. The surface of the platform is stainless steel corrugated plate
    5. The material of the escalator is stainless steel
