NovaStar, WG107, Mattress Manual Wrapping Machine, Max Mattress 2300x2000x300mm, 3Ph 380V 50Hz (New)

NovaStar, WG107, Mattress Manual Wrapping Machine, Max Mattress 2300x2000x300mm, 3Ph 380V 50Hz

Description

  1. Overview
    1. Main machine dimensions: 3430 × 1080 × 1300 mm
    2. Main machine assembling length: 4812 × 2678 × 1300 mm
    3. Working table dimensions: 2030 × 2560 × 800 mm
    4. Unloading table dimensions: 1885 × 507 × 656 mm
  2. Specifications
    1. Maximum mattress dimensions: 2300 (L) × 2000 (W) × 100-300 (H) mm
    2. Minimum mattress dimensions: 1000 (L) × 1900 (W) × 100-300 (H) mm
    3. Packing material: PE, PVC (≥ 0.11 mm) or polypropylene knitted bag
    4. Bag size: diameter φ415 mm
    5. Roll diameter: φ450 mm
    6. Productivity: 2-3 min/piece
  3. Power and Air Requirements
    1. Power supply: 3Ph 380V 50Hz (can change according to customer requirement)
    2. Total power: 4.1 kW
    3. Air pressure: 0.6-0.8 Mpa
