Flexible bellow at turbocharger outlet (after turbo) (4 sets)
Exhaust ducting from genset to chimney, total running 15 meters per set in silencer loop only, and flexible bellows (lot)
Support structure for above referred exhaust piping (lot)
Exhaust stack/chimney (4 units)
Cooling System
HT pump (4 units)
HT water circulating pump (8 units)
LT pump with motor (4 units)
Jacket water preheater (4 units)
TCV in HT circuit (4 units)
Mixture intercooler water thermostat (4 units)
Expansion water tank (HT + LT) (4 units)
Radiator in HT circuit (4 units)
Interface cooler (LT circuit) (4 units)
LT cooling water distribution system (lot)
Jacket water filling system (HT circuit)
Hot water piping from genset to VAM including pumps, valves, etc. (lot)
Lube Oil System
Fresh lube oil filling system comprising tank, pump, piping with necessary valves, bends and fittings (lot)
Lube oil cooler (4 units)
Lube oil filters (4 units)
Solenoid valves for automatic oil top up (4 units)
Arrangement for used lube oil (lot)
Starting System
Starting battery, 24 V (8 units)
Engine electric starter motor (4 units)
Cables with clamps (lot)
Charger for above 24 V battery (4 units)
Fuel Gas System
Fuel gas pipework along with necessary supports from the main gas valve up to the genset (lot)
Gas train unit (4 units)
Flexible gas pipe/hose (lot)
Gas flowmeter in the gas inlet line to engine (4 units)
Electrical Power and Control System
Control panel for engine management, control and supervision of all relevant functions of gas engine, with single synchroniser (4 units)
Master control panel (island mode/grid mode) (1 unit)
Battery bank with charging system for GCBP
Generator incomer power panel (4 units)
Plant auxiliary panel (PAP) for genset auxiliaries (1 unit)
Auxiliary transformer, bus PT and NGR panel (lot)
Earthing strips from earthing station to the earthing grid near the earthing pits (lot)
Earthing strips for vendor supplied electrical installations within the GE house (lot)
Electrical Installation Material
Power cables from alternator to the genset power panel (lot)
Control and instrument cables with termination kits, lugs, cable trays/racks etc. as required for interconnecting the system within the GE house between the genset and genset panel supplied by the vendor (lot)
General
Air conditioner for the control room (1 unit)
Ventilation system for giving provision for combustion air and room air flow out of the power house as per vendor requirement (lot)
