Description Overview Patterning needle loom, width 5200 mm Similar to Fehrer patterning looms Principle shaft and assist shaft double drive system Imported bearing for main drive system Crank is made of 40Cr, precision processed Handspike made of 38CrMoAl Circulating lubrication system Specifications Needle plate: 14 mm thick Needle density: 12000 stitches per minute Space between grate: 3.5 mm x 3.5 mm Needle stroke: 50 mm Frequency: 800 needles per minute Included Equipment 1 x unwinder, diameter 350 mm, steel tube 4400 mm long, wall thickness 10 mm 1 x accumulator, 3-roller, fabric storing roller 5400 mm, diameter 150 mm 1 x accumulator, 3-roller, fabric storing roller 5400 mm, diameter 150 mm 1 x winder and cutter, diameter 350 mm, steel tube 4400 mm, wall thickness 10 mm
