Description Overview Voltage: 220 V, 50/60 Hz Power: 1.7 kW Air delivery speed: 0.8 m³/min Minimum pressure required: 0.6 MPa Volume of tank: 0.6–0.8 m³ Filling Specifications Filling materials: down 70%–90% Filling port: 2 Down storage volume: 10–12 kg Single charge down weight: 0.1–30 Display accuracy: 0.01 Dynamic weighing error: ±0.03 g to ±0.05 g Cycle number: 3 Weight range: 0.1–30 g Accuracy grade: 0.01 g Scale quantity: 6 Multiple nozzle size: 16 mm or 19 mm Dimensions and Area Main body box size: 2.12 m x 0.88 m x 2 m Weight box size: 1.5 m x 0.55 m x 0.90 m Filling platform: 1 m x 0.6 m x 1.1 m Minimum transport channel: 1 m x 2.1 m Smallest placing area: 5 m x 3 m x 2.1 m Recommended placing area: 6 m x 4 m x 2.1 m Included Systems Pressure monitoring system included Humidification system included Packaging and Weight Package size: 2 cases: 2340 mm x 1010 mm x 2220 mm, 1640 mm x 1260 mm x 2180 mm Net weight: 750 kg Gross weight: 1150 kg CBM: 9.8 m³
