B+B Anlagenbau, PET Recycling Line, 2012, 1300 kg/hr Capacity, Unused

B+B Anlagenbau, PET Recycling Line, 2012, 1300 kg/hr Capacity, Unused

Description

  1. Pet Recycling Line
    1. Manufacturer: B+B Anlagenbau
    2. Year: 2012
    3. Never installed and still in boxes
    4. Raw material: Bottles
    5. End product: Pet chips
    6. Capacity: 1300 kgs per hour
    7. Specification n 1.1: The complex line for recycling of polyethylene terephtalate (pet) with processing capacity of 1300 kilos per hour
    8. Item 1.-10: Chain conveyor with bale buffer 5 m3
    9. Item 1.-20: Bale breaker zss 1500
    10. Item 1.-25: Steel construction for bale breaker
    11. Item 1.-30: Star screen 200-120
    12. Item 1.-35: Steel construction for star screen
    13. Item 1.-40: Belt
    14. Item 1.-46: Permanent magnetic roll (neodym)
    15. Item 1.-700/705: Bottle sorting unit pvc
    16. Item 1.-715: Sorting conveyor
    17. Item 1.-720: Bottle outfeed belt
    18. Item 1.-50: Sorting conveyor
    19. Item 1.-55: Steel construction for automatic/manual sorting
    20. Item 1.-60: Elevating conveyor belt
    21. Item 1.-64: Metal detection coil
    22. Item 1.-65: Discharge flap
    23. Item 1.-70: Grinder type gsh 700/1000
    24. Item 1/-75: Sound insulation
    25. Item 1.-80/90: Exhaust unit with evacuation cyclone and filter hood
    26. Item 1.-100: Dry cleaner type tr 100/250 -p/v
    27. Item 1.-105: Evacuation blower
    28. Item 1.-110: Cyclone with filter hood and rotary feeder
    29. Item 1.-115: Cyclone with filter hood and rotary feeder
    30. Item 1.-120: Zigzag classifier type zz 8/30
    31. Item 1.-122: Exhaust fan
    32. Item 1.-124: Cyclone with filter hood and rotary feeder
    33. Item 1.-125: Automatic metal removal system
    34. Item 1.-130: Steeping paddle screw
    35. Item 1.-140: Intensive washer iw 100/200 - p/v
    36. Item 1.-150: Hot washer hwk (continuous operation)
    37. Item 1.-160: Hot water circulation system
    38. Item 1.-170: Friction separato fa 60/200 - 2s
    39. Item 1.-175: Friction washer fa 60/200 - 2s
    40. Item 1.-180: Separating tank type 4 pw 1 as/ps-eco
    41. Item 1.-190: Feeding chute
    42. Item 1.-200: Mechanical drier type fh 100/150 -p/v
    43. Item 1.-202: Pet fines removal
    44. Item 1.-205: Bigbag holding/filling station type m (fines)
    45. Item 1.-210: Mechanical drier type r 38/50
    46. Item 1.-215: Collection auger and big bag holding and filling station
    47. Item 1.-220: Blower with aspiration hole and insulation
    48. Item 1.-225: Thermal drying
    49. Item 1.-230: Injector with rotary valve
    50. Item 1.-240: Metal separation unit 2 + 1/100
    51. Item 1.-250: Flake sorter type spekmag
    52. Item 1.-260: Injector with rotary valve
    53. Item 1.-265: Conveying fan
    54. Item 1.-268: Cyclone with filter hood and rotary feeder
    55. Item 1.-270: Air classifier type zz 4/300
    56. Item 1.-275: Conveying fan
    57. Item 1.-280: Cyclone with filter hood and rotary feeder
    58. Item 1.-285: Pneumatic diverter
    59. Item 1.-290/295: Big bag s double station
    60. Item 1.-300: Electric control panel
    61. Item 1.-B180308- 2: Bypass - computer
    62. Item 1.- 400: Steel construction
    63. Item 1-410: Pipes and transitions
    64. Item 1.-420: Cable and cable chases
    65. Item 1.- B002106: Spare and wear parts for pet recycling plant
    66. Item 1.-B002108- 200: Waste water treatment for pet recycling plant
    67. Item 1.- B002108-300: Steam generator junior 500
    68. Item 1.-B180308-3: Junior 500 chimney made from stainless steel for steam generator
    69. Item 1- B180308-1: Laboratory equipment
    70. Item 1- B180308-6: Compressor ga 7
    71. Item 1.-500: Assembly of plant by customer, startup and training
  2. Pe And Pp Recycling Line
    1. Manufacturer: B+B Anlagenbau
    2. Year: 2012
    3. Never installed and still in boxes
    4. Raw material: Films
    5. End product: Pe and pp granules
    6. Capacity: 650 kgs per hour
    7. Specification n 1.2: The complex line for recycling of polyethylene and polypropylene (pe and pp) with processing capacity of 650 kilos per hour
    8. Item 2.-10/20: Feed conveyor belt
    9. Item 2.-30: Shredder zerma
    10. Item 2.-40: Scratching chain conveyor
    11. Item 2.-45: Storage silo
    12. Item 2.-50: Vibrating table
    13. Item 2.-60: Magnetic drum permanent mtp 1003
    14. Item 2.-70: Transport auger
    15. Item 2.-80: Sifter for heavy separation
    16. Item 2.-90: Dry cleaning unit type tr 100/200 -v
    17. Item 2.-90.1: Transport unit
    18. Item 2.- 100: Steeping paddle screw
    19. Item 2.-110: Intensive washer type iw 100/150 t/v
    20. Item 2.- 120: Grinder gsh 600/800-5-3
    21. Item 2.- 130: Transport unit
    22. Item 2.-140: Separating tank trb 15/30 - 5 w - kk
    23. Item 2.-150: Friction separator fas 60/400
    24. Item 2.-155: Pneumatic diverter
    25. Item 2.-158: Transport screw
    26. Item 2.-160: Screw press scp 50
    27. Item 2.-170: Transport blower
    28. Item 2.-180: Thermal dryer td 50
    29. Item 2.-190: Air exchange unit
    30. Item 2.- 200: Transport blower with cyclone
    31. Item 2.-205: Pneumatic diverter
    32. Item 2-206: Pneumatic diverter
    33. Item 2-208: Big bag s double station
    34. Item 1-210: Electric control system
    35. Item 2.-220: Various pipelines, connections within the plant
    36. Item 2.-230: Various steel constructions within the plant
    37. Item 2.-235: Cable and cable chases
    38. Item 2.-B180308-4: Separate screws
    39. Item 2- B180308-7: Storage silo 10m3
    40. Item 2.- B180308-2: Bypass - computer
    41. Item 2.-B002108- 100: Waste water treatment for pe recycling plant
    42. Item 2.- B-08-6006: Plastic recycling machine into pellets
    43. Item 2.-B180308-5: Chiller type mk100
    44. Item 2.- B002107: Spare and wear parts for pet recycling plant
    45. Item 2.-B180308-6: Ga 7 compressor
    46. Item 1.-240: Assembly of plant by customer, startup and training
