Description Overview Briquetting diameter: 80 mm Motor: 11 kW Output: 20 to 50 kg per hour Approximately 7 cycles per minute with the machine at full capacity 3 cylinders 1 mono-bloc clamp Max. length of each expulsion: 70 mm 1 capacitance probe for automatic work 1 viewer Drum diam. 1.200 mm, volume capacity ~ 1 m³ End of cycle device Electronic pressure gauges, pump and clamp Siemens touch screen PLC Siemens display Counter Inductive limit switches Machine position control via LEDs Tapping head Pre-heating system Temperature and oil level probe Set up for oil cooling in the tank and output pipe material; for the correct work this machine needs the chiller system Current stabilizer Service keys Voltage: 480 V – 3 ph 60 Hz Standard painting: structure RAL 9010, protection casing RAL 9006 Max. moisture content: 15% Cooling Unit Specifications Must have a cooling unit Effective cooling capacity: 5.09 kW Compressor power: 1.40 kW Effective water flow: 0.884 m³/h Water side pressure: 5.56 kPa Reference temperature: 25.0 °C Water temperature output: 15.0 °C Inlet water temperature: 20.0 °C Number of compressors: 1 Number of circuits: 1 Number of fans: 1 Pump type: standard Head available (nom / min): 30/03 mH2O Fuel tank capacity: 25 liters Weight 1450 kg
